Westerschelde 22 March 2015 |
 |
 |
|
| Westerschelde 22/03/15 | Antwerpen 06/11/14 |
|
Name |
SAGA VIKING |
|
Type |
General cargo ship - Open-hatch - Box-Shaped - Single deck |
|
IMO-number |
9233466 |
|
Call sign |
VRXO6 |
|
Flag |
Hong Kong - China |
|
Port of registry |
Hong Kong |
|
GT |
29.867 t |
|
DWT |
46.882 t |
|
NT |
14.529 t |
|
Number of 20ft containers |
On deck: 400 In hold: 360 Total: 760 |
|
Length |
199,20 m overall 190,00 m between perpendiculars |
|
Breadth |
30,57 m extreme |
|
Draught |
11,82 m |
|
Depth |
16,40 m |
|
Speed |
14,9 knots |
|
Built |
2002 |
|
Keel laid |
10.09.2001 |
|
Launch date |
17.12.2001 |
|
Date of completion |
28.02.2002 |
|
Builder |
Oshima Shipbuilding Co. Ltd. |
|
Yard number |
10308 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Bulkheads |
Transverse: 13 Longitudinal: 2 |
|
Main engine |
1x Sulzer-Diesel United 7RTA52 - 2 stroke 7 cylinder diesel engine 8.952 kW |
|
Propellers |
1x Solid propeller |
|
Boilers |
1x Auxiliary boiler, composite GCS-19M Builder: Aalborg Industries A/S |
|
Generators |
3x Daihatsu 6DK-20 diesel generatorsets each 700 kW Builder: Daihatsu Diesel Mfg. Co., Ltd. |
|
Emergency generator |
1x Mitsiu diesel generatorset |
|
Number of hold |
10 |
|
Hold capacity |
Hold 1: 3.607 m³ / 127.380 ft³ Hold 2: 5.099 m³ / 180.069 ft³ Hold 2: 5.659 m³ / 199.846 ft³ Hold 4: 5.659 m³ / 199.846 ft³ Hold 5: 5.659 m³ / 199.846 ft³ Hold 6: 5.659 m³ / 199.846 ft³ Hold: 7: 5.659 m³ / 199.846 ft³ Hold 8: 5.659 m³ / 199.846 ft³ Hold 9: 5.659 m³ / 199.846 ft³ Hold 10: 4.913 m³ / 173.501 ft³ Total bale : 53.232 m³ / 1.879.872 ft³
|
|
Number of hatches |
10 Dimensions: 13,20 x 25,30 m each |
|
Ballast caoacuty |
16.604 m³ |
|
Anchor equipment |
Length: 632,50 m Diameter: 73 mm |
|
Cargo gear |
2x Cranes - SWL 42 t travelling gantry cranes with weather protection |
|
Manager |
Anglo-Eastern Ship Management Ltd. |
|
Operator |
Saga Welco |
|
Owner |
Saga Forest Carriers International |
|
Registered owner |
J.Y.S Shipping, S.A. |
|
Previous owners |
2002 - 2002 Nippon Yusen Kaisha 2002 - 2012 Beat Shipping S.A. |
|
Latest data adjustment |
03 May 2015 |
