Westerschelde 16 June 2019 |
 |
 |
|
| Westerschelde 22/04/15 | Antwepen 03/05/16 |
|
Name |
NASSAUBORG |
|
Type |
Multi-purpose dry cargo carrier - Singledecker - Strengthened for heavy cargoes |
|
IMO-number |
9248564 |
|
Call sign |
PHDU |
|
Flag |
The Netherlands |
|
Port of registry |
Delfzijl |
|
GT |
16.037 t |
|
DWT |
20.396 t |
|
DWCC |
Summer: 19.600 t |
|
NT |
6.827 t |
|
Number of 20ft containers |
658 |
|
Length |
174,10 m overall 165,70 m between perpendiculars |
|
Breadth |
22,00 m |
|
Draught |
9,38 m |
|
Air draft |
35,50 m in ballast |
|
Depth |
12,81 m moulded |
|
Speed |
Service: 12,0 knots Max: 16,0 knots |
|
Built |
2006 2007 lengthened at Cosco Shipyard, Zhousan - China |
|
Keel laid |
17/05/2002 |
|
Launch date |
20/05/2004 |
|
Date of completion |
18/01/2006 |
|
Builder |
Fujian Mawei Shipbuilding Mawei China |
|
Yard number |
436/4 |
|
Hull material |
Steel |
|
Hull type |
Double skinned |
|
Continuous decks |
1 |
|
Main engine |
1x MAN-B&W/Hyundai 6S50MC - 4 stroke single acting 6 cylinder 500 x 2.000 mm combustion engine 9.480 kW / 12.889 bhp at 127,0 rpm |
|
Propellers |
1x Controllable pitch propeller |
|
Generators |
1x Generator 1.600 kW 3x Generators each 680 kW |
|
Bow thruster |
1x 1.000 kW |
|
Number of holds |
4x Fully box and double skinned hold 1: 24,80 x 18,80 x14,00 m hold 2: 27,40 x 18,80 x14,00 m hold 3: 27,40 x 18,80 x14,00 m hold 4: 24,80 x 18,80 x14,00 m |
|
Hold capacity |
Grain/bale: 18.498 m³ / 934.919 ft³ |
|
Hold ventilation |
60.000 - 40.000 m³ per hour basis empty holds All holds fitted with dehumidifier system |
|
Number of hatches |
4 Hatch 1-4: each 24,80 x 18,80 m |
|
Tank capacities |
HFO: 1.016 m³ MGO: 150 m³ Water ballast: 8.284 m³ Fresh water: 90 m³ |
|
Cargo gear |
3x Cranes - SWL 35,0 t each |
|
Manager |
Wagenborg Shipping Delfzijl The Netherlands |
|
Operator |
Wagenborg Shipping |
|
Owner |
Eems Holding B.V. (C.V. m.s. Nassauborg) Delfzijl The Netherlands |
|
Previous owners |
01/2000 - 03/2011 Wagenborg Rederij B.V., Delfzijl - The Netherlands |
|
Latest data adjustment |
17 September 2021 |
