Name |
BALTIC KLIPPER |
|
Type |
Refrigerated carrier / Container ship - Equipped for the carriage of vehicles |
|
IMO-number |
9454759 |
|
Call sign |
A8VR5 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
GT |
14.091 t |
|
DWT |
Summer: 15.693 t |
|
NT |
7.238 t Panama: 11.824 t Suez: 12.766,65 t |
|
Number containers |
267 FEU + 9 TEU or 552 TEU |
|
Reefer plugs |
200 |
|
Length |
165,00 m overall 153,50 m between perpendiculars |
|
Breadth |
25,00 m |
|
Draught |
Summer: 10,32 m Winter: 10,10 m |
|
Freeboard |
3.712 mm |
|
Depth |
14,00 m |
|
Speed |
Max: 23,2 knots Service: 20,4 knots |
|
Built |
2010 |
|
Launch date |
18/05/2010 |
|
Date of completion |
07/09/2010 |
|
Builder |
Kitanihon Shipbuilding Co., Ltd. Hachinohe Japan |
|
Yard number |
391 |
|
Hull material |
Steel |
|
Watertight compartments |
10 |
|
Main engine |
1x MAN-B&W/Hitachi - 2 stroke 6 cylinder 600 x 2.400 mm combustion engine 14.280 kW / 19.402 hp at 105,0 rpm Built: 10/02/2010 Builder: Hitachi Zosen Corporation Ariake Works, Ariake - Japan |
|
Propellers |
1x Fixed pitch propeller - aft at 105,0 rpm |
|
Boilers |
1x CHR Miura Co., Ltd. 168,30 m² - 9,8 bar 1x CHO Miura Co., Ltd 37,80 m² - 9,8 bar |
|
Generators |
4x Main diesel generatorsets each 1.875 kVA - 1.500 kW - 2.201 hp |
|
Emergency generator |
1x Diesel generatorset 150 kVA - 120 kW - 190 hp |
|
Bow thruster |
1x 1.000 kW |
|
Holds / Hatches / Compartments |
4 / 4 / 16 |
|
Total capacity of holds |
17.876,41 m³ / 661.636 ft³ |
|
Floorspace |
7.118,2 m² |
|
Pallets |
5.400 |
|
Cooling sections |
8 |
|
Tank capacities |
Fuel oil: 2.000,78 m³ Marine diesel oil: 100 t |
|
Cargo gear |
2x Cranes - SWL 40,0t each 2x Cranes - SWL 8,0 t each |
|
Operator |
Geest Reefer Line |
|
ISM & commercial manager |
Seatrade Groningen Leonard Sprinerlaan 17 9727 KB Groningen The Netherlands |
|
Registered owner |
Baltic Klipper Shipping Company N.V. C/o Seatrade Groningen BV Laan Corpus den Hoorn 200 9728 JS Groningen The Netherlands |
|
Latest data adjustment |
26 January 2023 |
