Name |
KWINTEBANK |
|
Type |
Multi-purpose dry cargo carrier - Heavycargo - Container ship |
|
IMO-number |
9234288 |
|
Call sign |
PBGT |
|
Flag |
The Netherlands |
|
Port of registry |
Delfzijl |
|
GT |
6.378 t |
|
DWT |
Summer: 9.777 t |
|
NT |
3.099 t |
|
Number of 20ft containers |
552 |
|
Reefer capacity |
25 |
|
Length |
132,23 m overall 123,84 m between perpendiculars |
|
Breadth |
15,87 m |
|
Draught |
7,76m |
|
Air draft |
33,00 m |
|
Freeboard |
1.908 mm |
|
Depth |
11,15 m |
|
Speed |
15,0 knots |
|
Built |
2002 |
|
Launch date |
2002 |
|
Delivery date |
09/08/2002 |
|
Builder casco |
Deawoo-Mangalia Heavy Industries S.A. Mangalia Romania Yard number: 1031 |
|
Builder completion |
Bodewes Scheepswerf Volharding Foxhol B.V. Foxhol The Netherlands Yard number: 503 |
|
Hull material |
Special steel |
|
Watertight compartments |
6 |
|
Continuous decks |
1 |
|
Main engine |
1x MaK-Caterpillar 8M32 - 4 stroke 8 cylinder 320 x 480 mm combustion engine 4.030 kW / 5.476 hp at 600 rpm Built: 04/12/2001 Builder: Caterpillar Motoren GmbH & Co. KG, Kiel - Germany |
|
Propellers |
1x Screw propeller controllable pitch - aft at 148 rpm |
|
Boilers |
1x CHO Aalborg 17,50 m² - 13,0 bar 1x CHR Aalborg 77,00 m² - 13,0 bar |
|
Electric installations |
Power voltage: 440 V Lighting voltage: 230 V Frequency: 60 Hz |
|
Shaft generator |
1x 813 kVA - 650 kW |
|
Generators |
2x Main diesel generatorsets each 325 kVA - 260 kW - 376 hp |
|
Emergency generator |
1x Diesel generatorset 87 kVA - 70 kW - 109 hp |
|
Bow thruster |
1x 500 kW |
|
Number of holds |
2 Hold 1: 39,90 x 13,20 x 10,84 m Hold 2:52,50 x 13,20 x 10,84 m |
|
Total capacity of holds |
Grain: 12.814 m³ / 454.000 ft³ |
|
Cargo Hatchways: |
2 Hatch 1: 39,90 x 13,20 m Hatch 2: 52,50 x 13,20 m |
|
Tank capacities |
Fuel oil: 453 m³ |
|
Cargo gear |
Gearless |
|
ISM & Commerical manager |
Pot Scheepvaart Handelskade West 28-A 9934 AA Delfzijl The Netherlands |
|
Operator |
Wagenborg Shipping B.V. Marktstraat 10 9934 CK Delfzijl The Netherlands |
|
Registered owner |
Kwinteship B.V. Handelskade West 28 A 9934 AA Delfzijl The Netherlands |
|
Latest data adjustment |
28 March 2022 |
