Westerschelde 04 August 2016 |
 |
| Westerschelde 25/11/15 |
|
Name |
NAJA |
|
Previous names |
1997 - 1997 Lebasee name when launched 1997 - 1997 Sao Vicente 1997 - 2006 Lebasee 2006 - 2007 Moldavia 2007 - 2007 Herford 2007 - 2009 Anne Scan 2009 - 2015 Anne |
|
Type |
General cargo ship - Equipped for carriage of containers - Strengthened for heavy cargo |
|
IMO-number |
9145126 |
|
Call sign |
V2IA8 |
|
Flag |
Antigua & Barbuda |
|
Port of registry |
St. John's |
|
Previous flags |
1997 - 1997 Germany |
|
GT |
2.528 t |
|
DWT |
Summer: 3.526 t incl bulkheads |
|
DWCC |
Summer: 3.250 t Winter: 3.150 t |
|
NT |
1.372 t |
|
Number of 20ft containers |
167 |
|
Reefer capacity |
18 |
|
Length |
85,51 m overall 81,00 m between perpendiculars |
|
Breadth |
12,80 m extreme |
|
Draught |
5,54 m |
|
Air draft |
25,90 m ballast |
|
Depth |
7,10 m moulded |
|
Speed |
12,5 knots |
|
Built |
1997 |
|
Keel laid |
10.06.1996 |
|
Launch date |
10.12.1996 |
|
Date of completion |
01.03.1997 |
|
Builder |
Slovenske Lodenice A.S. |
|
Yard number |
1412 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Movable bulkheads |
2x Movable units various positions |
|
Main engine |
1x MAN 7L28/32 A - 7 cylinder diesel engine 1.715 kW |
|
Propellers |
1x Controllable pitch propeller |
|
Boilers |
1x Auxiliary boiler, oil/gas fired |
|
Shaft generator |
1x 376 kW |
|
Generators |
2x MAN D2866 LE diesel engine coupled with Leroy Somer generator |
|
Emergency & harbour gen. |
1x MAN D0226 ME diesel generatorset |
|
Bow thruster |
1x 185 kW |
|
Number of holds |
1 56,55 x 10,20 x 8,10 m |
|
Tweendeck |
49,70 x 10,20 m Adjustable height: Hold bottom to lower position: 4,20m Hold bottom to upper position: 5,50 m Lower position twd to hatch coaming: 3,45 m Upper position twd to hatch coaming: 2,35 m |
|
Cargo hold capacity |
163.000 ft³ / 4.615 m³ |
|
Hatch cover type |
Kvaerner type |
|
Max. permitted loads |
Tanktop: 20,0 t/m² Tween Deck: 2,50 t/m² Deck strength: 1,60 t/m² |
|
Tank capacities |
Ballast: 1.515 m³ |
|
Anchor equipment |
Length: 440,00 m Diameter: 34 mm |
|
Cargo gear |
2x NMF Cranes - SWL 35,0 t each |
|
Manager |
Reederei Erwin Strahlmann GmbH & Co. KG |
|
Previous managers |
1997 - 2001 Reederei Triton Schiffahrts GmbH & Co. KG 2001 - 2006 Triton Schiffahrts GmbH 2006 - 2015 Held Bereederungs GmbH & Co. KG 2015 - 2015 Schifffahrtskontor Erwin Strahlmann e.K. |
|
Operator |
R.E.S. Chartering GmbH |
|
Registered owner |
LAPPAN Shipping & Trading GmbH & Co. KG |
|
Previous owners |
1997 - 2006 Triton Schiffahrts GmbH & Co. KG MS "LEBASEE" 2006 - 2007 ShipCom Bereederungs GmbH & Co. Betriebs-KG MS "MOLDAVIA" 2007 - 2011 Mardex Schiffahrts GmbH & Co. KG MS "HASETAL" 2011 - 2015 NORDICA Schiffahrts GmbH & Co. KG MS "Herford" |
|
Latest data adjustment |
19 January 2016 |
