Name |
SVETI DUJAM |
|
Type |
Bulk carrier |
|
IMO-number |
9519638 |
|
Call sign |
9AA7459 |
|
Flag |
Croatia |
|
Port of registry |
Split |
|
GT |
30.092 t |
|
DWT |
Summer: 52.113 t |
|
NT |
17.852 t |
|
Length |
189,90 m overall 182,00 m between perpendiculars |
|
Breadth |
32,24 m |
|
Draught |
Max: 12,37 m |
|
Freeboard |
4.775 mm |
|
Depth |
17,10 m |
|
Speed |
14,3 knots |
|
Built |
2010 |
|
Keel laid |
04/08/2009 |
|
Date of completion |
22/09/2010 |
|
Builder |
Brodosplit - Brodogradiliste d.o.o Croatia |
|
Yard number |
467 |
|
Hull material |
Steel |
|
Watertight compartments |
18 |
|
Continuous decks |
1 |
|
Main engine |
1x MAN-B&W 6S50MC-C - 2 stroke 6 cylinder 500 x 2.000 mm combustion engine 8.600 kW / 11.685 hp at 12,0 rpm Builder: Tvornica Diesel Motora-Split, Split - Croatia |
|
Propellers |
1x Screw Propeller Solid - aft at 121,0 rpm |
|
Boilers |
1x CHM Saacke Marine System 228,00 m² - 7,0 bar |
|
Generators |
3x Main diesel generatorsets each 775 kVA - 620 kW - 883 hp |
|
Emergency generator |
1x Diesel generatorset 170 kW |
|
Number of holds |
5 |
|
Total capacity of holds |
Grain: 64.985,5 m³ - 2.294.829 ft³ |
|
Number of hatches |
5 |
|
Tank capacities |
Fuel: 1.901,8 m³ |
|
Anchor equipment |
Length: 635,50 m Diameter: 73 mm |
|
Cargo gear |
4x Cranes - SWL 35,0 t each |
|
Operator |
Jadroplov International Maritime Transport Ltd (Jadroplov dd) Obala kneza Branimira 16 21000 Split Croatia |
|
Registered owner |
Radunica Maritime Inc. c/o Jadroplov International Ma, (Jadroplov dd) Obala kneza Branimira 16 HR-21000 Split Croatia |
|
Latest data adjustment |
28 March 2020 |
