Antwerpen 26 May 2016 |
 |
| Antwerpen 26/05/16 |
|
Name |
ANTON |
|
Previous names |
Karelia - Republic of Panama, Panama city - call sign: 3EXN6 |
|
Type |
Multi-purpose dry cargo ship - Equipped for carriage of containers - Strengthened for heavy cargo Singledecker |
|
IMO-number |
9576703 |
|
Call sign |
V2GR6 |
|
Flag |
Antigua & Barbuda |
|
Port of registry |
St. John's |
|
GT |
2.997 t |
|
DWT |
4.497 t |
|
DWCC |
Summer: 4.290 t Winter: 4.150 t |
|
NT |
1.598 t |
|
Number of 20ft containers |
In hold: 102 On hatches: 36 Total: 138 |
|
Length |
89,99 m overall 85,80 m between perpendiculars |
|
Breadth |
14,02 m extreme |
|
Draught |
5,81 m moulded |
|
Air draft |
25,80 m |
|
Depth |
7,15 m to main deck |
|
Speed |
Service: 10,0 knots |
|
Built |
2010 |
|
Keel laid |
25.12.2009 |
|
Launch date |
08.06.2010 |
|
Date of completion |
23.07.2010 |
|
Builder |
Onega Shipbuilding Yard CJSC |
|
Yard number |
205 |
|
Hull material |
Steel |
|
Movable bulkheads |
1x Moveable grain bulkhead with 4 stowage positions |
|
Main engine |
1x Wärtsilä 6L26 B2 - 6 cylinder diesel engine 1.950 kW / 2.650 hp |
|
Propellers |
1x Controllable pitch propeller |
|
Boilers |
1x Thermal oil heater, exhaust heated 1x Thermal oil heater, oil fired |
|
Shaft generator |
1x 300 kW - 50Hz |
|
Generators |
2x D9A MG HE/KC main diesel generatorsets 261 kW - 50 Hz |
|
Emergency generator |
1x D7A-T diesel generatorset 112 kVA - 50 Hz |
|
Compressed air receivers |
2x Starting air compressors |
|
Bow thruster |
1x Fixed pitch propeller 170 kW |
|
Number of holds |
1x Boxshaped hold narrowing fore and aft 58,80 x 11,47 x 8,24 m |
|
Hold capacity |
Grain: 5.527 m³ / 195.154 ft³ |
|
Number of hatches |
1x Steel pontoon hatches with 1 gantry crane 55,20 x 11,47 m |
|
Air change |
6 Times |
|
Max. permitted loads |
Tanktop: 12,0 t/m² Haych cover: 2,7 t/m² |
|
Tank capacities |
Ballast: 1.983 m³ MGO: 286 m³ Potable water: 56 m³ |
|
Anchor equipment |
Length: 440,00 m Diameter: 40 mm |
|
Accommodation |
For captain and crew of a total 10 persons with heating, ventilation and air-conditioning |
|
Manager |
Hermann Lohmann Schiffahrtsverwaltungs GmbH |
|
Operator |
HLB Hermann Lohmann Bereederungen GmbH & Co. KG |
|
Owner |
Hermann Lohmann Schiffahrts GmbH & Co. KG MS 'ANTON' Haren/Ems |
|
Previous names & owners |
Karelia - Baltasar Shipping S.A. |
|
Renamed |
2016 Wilson Halmstad, Antigua & Barbuda - Call sign: V2GR6 |
|
Latest data adjustment |
04 August 2016 |
