Name |
BONTRUP PEARL |
|
Previous names |
1984 - 01/1991 Heina 01/1991 - 06/2012 Auk Arrow 06/2012 - 2016 Point Lisas Pearl |
|
Type |
Self-discharging general cargo ship - Forest product carrier - Open hatch box shaped |
|
Main products |
Container carriage - Dry bulk forest products carriage - Heavy dry bulk cargo carriage |
|
IMO-number |
8309397 |
|
Call sign |
C6KB2 |
|
Flag |
Bahamas |
|
Port of registry |
Nassau |
|
GT |
27.962 t |
|
DWT |
Summer: 43.005 t Winter: 41.771 t |
|
NT |
12.660 t |
|
Lightship |
10.309 t |
|
Number of 20ft containers |
1.392 |
|
Length |
187,50 m overall 180,85 m between perpendiculars |
|
Breadth |
29,04 m extreme |
|
Draught |
Summer: 12,30 m Winter: 12,05 m |
|
Freeboard |
4.644 mm |
|
Depth |
16,92 m |
|
Speed |
13,4 knots |
|
Built |
1984 |
|
Keel laid |
02/11/1983 |
|
Launch date |
01/02/1984 |
|
Date of completion |
05/05/1984 |
|
Builder |
Sanoyasu Shipbuilding Corporation Kurashiki Japan |
|
Yard number |
1060 |
|
Hull material |
Steel |
|
Hull type |
Double skin |
|
Continious decks |
1 |
|
Main engine |
1x Sumitomo Sulzer 6RTA58 - 2 stroke 6 cylinder 580 x 1.700 mm combustion engine 6.330 kW / 8.600 bhp at 95,0 rpm |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Gadeli Sunrod PT-11 auxiliary boiler, exhaust gas heated - 11,00 bar 1x Svenna Sunrod CPDB-15 auxiliary boiler, oil/gas fired - 8,0 bar |
|
Generators |
3x Yanmar T260L-ST main diesel generatorsets each 875 kVA - 700 kW - 1.050 hp |
|
Emergency generator |
1x Deutz BF6L913C diesel generatorset 80 kW |
|
Bow thruster |
1x Vicker TC-200N side thruster |
|
Number of holds |
7 Hold 1: NA Hold 2-4-6: 24,72 x 23,00 x 16,77 m Hopd: 3-5: 12,44 x 23,00 x 16,77 m Hold 7: 12,44 x 23,00 x 15,93 m |
|
Hold capacity |
Grain: 47.405,3 m³ |
|
Number of hatches |
7 Hatches: 2-4-6: 24,72 x 23,00 m Hatches: 3-5-7: 12,44 x 23,00 m |
|
Hatch type |
Hatch covers with cement feeder holes |
|
Self-Unloading boom |
Main boom: 60,00 m Telescopic boom (total /work): 27,50 m / 18,50 m Slewing / Rotations: -90-0+85 deg Max unloading speed: 2.200 t/h Average unloading speed: 1.750 t/h |
|
Tank Capacities |
Fuel: 2.971,9 m³ |
|
Cargo gear |
2x Mitsui-Paceco gantry cranes - SWL 35,0 t - 10,00 m outreach either side 3x Grabs each 13 m³ Grab fitted/self load/self discharging |
|
Person Capacity |
40 |
|
Commerical manager |
SMT Shipmanagement & Transport ul 8 Boleslawa Chrobrego 48 81-723 Sopot Poland |
|
ISM manager |
SMT Shipping Poland Sp. z o.o. ul 8 Boleslawa Chrobrego 48 81-723 Sopot Poland |
|
Registered owner |
Bontrup Pearl Ltd. Care of SMT Shipmanagement & Transport Gdynia Ltd. Sp. z.o.o ul Boleslawa Chrobrego 48 81-723 Sopot Poland |
|
Latest data adjustment |
25 April 2022 |
