Westerschelde 18 April 2015 |
 |
| Westerschelde 18/04/15 |
|
Name |
ONEGO PIONEER |
|
Previous names |
1999 - 03.2001 Atlantic Pioneer 03.2001 - 01.2007 Seaboard Pioneer 01.2007 - 09.2011 Federal Pioneer 09.2011 - 06.2013 CCNI Tumbes 06.2013 - 04.2015 Atlantic Pioneer |
|
Type |
General cargo ship - Equipped for carriage of containers - Strengthened for heavy cargo Singledeck/Tweendeck Box-shaped Open-hatch |
|
IMO-number |
9190080 |
|
Call sign |
P3QY8 |
|
Flag |
Cyprus |
|
Port of registry |
Limassol |
|
GT |
12.993 t |
|
DWT |
Summer: 17.530,6 t Winter: 16.934,7 t |
|
NT |
5.894 t |
|
Number of 20ft containers |
On deck: 710 In hold: 4058 Total: 1.118 |
|
Number of 40ft containers |
On deck: 311 + 37 TEU In hold: 193 + 22 TEU Total: 504 + 59 TEU |
|
Length |
143,11 m overall 133,00 m between perpendiculars |
|
Breadth |
23,13 m |
|
Draught |
Summer: 9,72m |
|
Depth |
13,30 m to main deck |
|
Speed |
13,0 knots |
|
Built |
1999 |
|
Keel laid |
25.09.1998 |
|
Launch date |
16.04.1999 |
|
Date of completion |
21.10.1999 |
|
Builder |
Jingjiang Shipyard |
|
Yard number |
JS98-010 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x MAN 7L42 MC - 7 cylinder diesel engine 6.965 kW at 176 rpm |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Auxiliary boiler, composite - OVS-120/60-24 |
|
Generators |
3x MAN Holeby 5L16/24 main diesel generatorsets each 500 kW at 1.200 rpm |
|
Emergency generator |
1x Volvo TAMD 71 B diesel generatorset 475 kW |
|
Bow thruster |
1x Kawasaki controllable pitch propeller 500 kW |
|
Number of holds |
3 Hold 1: 22,30 x 13,25 x11,80 m Hold 2: 42,36 x 18,60 x 13,90 m Hold 3: 28,20 x 18,60 x 13,90 m |
|
Cargo hold capacity |
Grain & Bale Hold 1: 126.232 ft³ / 3.574 m³ Hold 2: 384.025 ft³ / 10.870 m³ hold 3: 255.999 ft³ / 7.249 m³ Total: 766.256 ft³ / 21.693 m³ |
|
Cargo hold ventilation |
6x Air-changes per hour |
|
Number og hatches |
3 Hatch 1: 20,50 x 13,21 m Hatch 2: 38,80 x 18,60 m Hatch 3: 26,20 x 18,60 m |
|
Hatch cover type |
McGregor Hydraulic Folding |
|
Timber stanchions |
6,00 m high |
|
Max. permitted loads |
Tanktop: 20,0 t/m² Tweendeck: 4,7 t/m² |
|
Tank capacities |
IFO: 1.526 m³ (98%) MDO: 145 m³ (98%) Fresh water: 335.5 m³ (100%) Water ballast: 5.809 m³ (100%) |
|
Anchor equipment |
Length: 577,50 m Diameter: 60 mm |
|
Cargo gear |
2x Cranes - SWK 45,0 t each combinable upto 80,0 t port side |
|
Crew size |
22 |
|
Operator |
Onego Shipping & Chartering B.V. |
|
Latest data adjustment |
21 November 2016 |
