Westerschelde 24 April 2017 |
 |
 |
|
| Westerschelde 28/04/17 | Antwerpen 31/10/17 | |
|
Name |
WILSON DUNDEE |
|
Previous names |
2009 - 09/2014 Theseus |
|
Type |
Multi-purpose dry cargo ship - Equipped for carriage of container - Boxshaped |
|
IMO-number |
9390159 |
|
Call sign |
8PBL2 |
|
Flag |
Barbados |
|
Port of registry |
Bridgetown |
|
Previous flag |
Antigua & Barbuda, St. John's - Call sign: V2FQ9 |
|
GT |
2.452 t |
|
DWT |
Summer: 3.666,56 t Winter: 3.534 m |
|
NT |
1.369 t |
|
Number of 20 ft containers |
On deck: 36 |
|
Length |
87,73 m overall 81,24 m between perpendiculars |
|
Breadth |
12,90 m extreme 12,80 m moulded |
|
Draught |
Summer: 5,51 m Winter: 5,40 m |
|
Air draft |
21,60 m |
|
Keel to top antenna fwd/aft |
20,30/25,35 m |
|
Keel to top antenna fwd/aft |
11,50/19,00 m lowered mast |
|
Depth |
7,10 m moulded |
|
Speed |
Max: 11,7 knots Service: 9,0 knots |
|
Built |
2009 |
|
Keel laid |
18/06/1998 |
|
Launch date |
20/03/2009 |
|
Date of completion |
25/06/2009 |
|
Builder |
Slovenske Lodenice Komarno a.s. Komarno Slovakia |
|
Yard number |
2978 |
|
Hull material |
Steel |
|
Movable bulkheads |
2x Moveable bulkheads with 10 positions and 2 storage positions |
|
Main engine |
1x MaK 8M20C - 4 stroke 8 cylinder combustion engine 1.500 kW |
|
Propellers |
1x Controllable pitch propeller |
|
Boilers |
1x Auxiliary boiler, oil/gas fired 1(oil fired water heater) |
|
Generators |
2x Sisu Diesel 645 DSBIG main diesel generatorsets each 126 kVA |
|
Emergency generator |
1x Sisu Diesel 320 DSG diesel generatorset 50 kVA |
|
Bow thruster |
1x 185 kW |
|
Number of holds |
1 56,55 x 10,20 x 8,13 m |
|
Cargo hold capacity |
162.025 ft³ / 4.588 m³ 4.672 m³ without bulkheads |
|
Hold ventilation |
6 Times |
|
Number of hatches |
1 56,55 x 10,20 m |
|
Hatch type |
Kvaerner Multifold crocodile, with hydraulic control |
|
Max. permitted loads |
Tanktop: 15,0 t/m² Deck/hatch cover: 1,60 t/m² |
|
Tank capacities |
Water ballast: 1.340,4 m³ MGO: 175 m³ IFO: 90 m³ |
|
Anchor equipment |
Length: 440,00 m Diameter: 32 mm |
|
Manager |
Wessels Reederei GmbH & Co. KG Industriestraße 12 49733 Haren (Ems) Germany |
|
Operator |
Wilson ASA Bradbenken 1 N-5835 Bergen Norway |
|
Registered owner |
Wilson Shipowning AS |
|
Latest data adjustment |
13 April 2023 |
