Antwerpen 19 July 2015 |
 |
|
| Westerschelde 31/07/15 | |
|
Name |
INDUSTRIAL CHIEF |
|
Previous names |
Build as: 2000 Harun J 10/2000 - 11/2000 Industrial Chief 11/2000 - 09/2003 Harun J 09/2003 - 09/2006 Industrial Chief 09/2005 - 03/2014 Ocean Titan |
|
Type |
General cargo ship - Equipped for carriage of containers - Heavy lift vessel |
|
IMO-number |
9213947 |
|
Call sign |
V7VP6 |
|
Flag |
Marshall Islands |
|
Port of registry |
Majuro |
|
GT |
7.252 t |
|
DWT |
Summer: 8.040,4 t |
|
NT |
2.982 t |
|
Number of 20ft containers |
On deck: 302 In hold: 214 Total: 516 |
|
Number of 40ft containers |
On deck: 104 In hold: 146 Total: 250 |
|
Reefer plugs |
80 |
|
Length |
119,81 m overall 112,00 m between perpendiculars |
|
Breadth |
20,00 m extreme |
|
Draught |
Summer: 7,71 m Winter: 7,55 m |
|
Depth |
11,30 m |
|
Speed |
16,0 knots Economic: 13,0 knots |
|
Built |
2000 |
|
Keel laid |
26/02/1999 |
|
Launch date |
28/05/2000 |
|
Date of completion |
01/08/2000 |
|
Builder |
ENVC - Estaleiros Navais de Viana do Castelo, S.A. Viana do Castelo Portugal |
|
Yard number |
218 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x MaK 6M43 - 6 cylinder combustion engine 5.400 kW / 7.341 bhp at 500 rpm Build: 2000 Builder: MaK Motoren GmbH & Co. KG, Kiel - Germany |
|
Propellers |
1x Variable pitch propeller |
|
Boilers |
1x Thermal oil heater, oil fired 1x Thermal oil heater, exhaust heated |
|
Generators |
2x Mitsubishi S6A3MPTK main diesel generatorsets each 442 kW 1x Mitsubishi S6A3MPTA main diesel generatorset 700 kW Builder: Mitsubishi Heavy Industries Engine & Turbocharger, Ltd. - Japan |
|
Bow thruster |
450 kW |
|
Number of cargo holds |
3 Hold 1: 12,77 x 10,42 / 5,20 x 9,67 m Hold 2: 38,38 x 15,77 x 12,19 m Hold 3: 12,77 x 15,75 x 9,67 m |
|
Cargo hold capacity |
Bale: 10.532 m³ / 371.934 ft³ Bale without tweendeck: 11.597 m³ / 409.544 ft³ |
|
Hold ventilation |
6x Air changes per hour |
|
Number of hatch covers |
3 Hatch 1:12,93 x 15,77 / 10,60 m Hatch 1a: 4,07 x 13,04 m Hatch 2: 38,00 x 15,77 m Hatch 2a: 4,07 x 13,04 m Hatch 3: 12,93 x 15,77 m |
|
Hatch cover type |
Pontoon |
|
Tween deck |
Positions: Hold 1: 1 position Hold 2: 3 positions Hold 3: 2 positions |
|
Tween deck heights |
Hold 1: Pos 1: 3,515 m / 5,360 m Hold 2: Pos 1: 3,135 m / 8,260 m Hold 2: Pos 2: 6,035 m / 5,360 m Hold 2: Pos 3: 8,335 m / 3,060 m Hold 3: Pos.1: 3,515 m / 5,360 m Hold 3: Pos 2: 5,815 m / 3,060 m |
|
TWD cover type |
Pontoon |
|
Max. permitted loads |
Tanktop: 15.0 t/m² Tweendeck hatch: 3.5 t/m² Weatherdeck hatch: 2,5 t/m² |
|
Tank capacities |
Ballast: 4.195,5 m³ HFO: 651,36 m³ MGO: 86,44 m³ Fresh water: 165,61 m³ |
|
Anchor equipment |
Length: 554,80 m Diameter: 58 mm |
|
Cargo gear |
2x Electric hydraulic cranes - SWL 200 t each Combinable up to 400 t |
|
Manager |
Jüngerhans Heavy-Lift-Fleet Services GmbH & Co., KG Boschstraße 31 49733 Haren (Ems) Germany |
|
Registered owner |
Heavylift Shipowning LLC |
|
Renamed |
2017 Orient Pluto Saint Vincent & the Grenadines, Kingstown - Call sign: J8B5631 Fatima V Indonesia, Pelabuhan Pendaftaran - Call sign: YDPL2 Owner & operator: PT. Pelayaran Samasagung Tunggalperkasa, Surabaya - Jawa Timur - Indonesia |
|
Latest data adjustment |
02 April 2024 |
