Name |
BBC VESUVIUS |
|
Type |
Multi-purpose dry cargo ship - Equipped for carriage of containers - Strengthened for heavy cargo - Tweendecker - Heavylifter |
|
IMO-number |
9508471 |
|
Call sign |
V2GB4 |
|
Flag |
Antigua & Barbuda |
|
Port of registry |
St. John's |
|
GT |
8.255 t |
|
DWT |
Summer: 9.282 t Abt.9.600 t without tweendecks Abt. 8.900 t with tweendecks |
|
NT |
3.966 t |
|
Number of 20ft containers |
In hold: 262 On deck: 398 Total: 660 |
|
Number of 40ft containers |
In hold: 112 + 38 TEU On deck: 166 + 66 TEU Total: 278 + 104 TEU |
|
Container capacity 14t |
377 |
|
Reefer sockets |
60 at different positions / increase of sockets possible |
|
Length |
125,79 m overall 119,66 m between perpendiculars |
|
Breadth |
22,32 m extreme |
|
Draught |
Summer: 7,60 m |
|
Height above keel |
38,15 m |
|
Depth |
10,80 m to main deck |
|
Speed |
16,5 knots |
|
Built |
2012 |
|
Keel laid |
10/12/2008 |
|
Launch date |
10/07/2012 |
|
Date of completion |
29/11/2012 |
|
Builder |
Tianjin Xingang Shipbuilding Heavy Industry Co., Ltd. China |
|
Yard number |
SB357-7 |
|
Hull material |
Steel |
|
Movable bulkheads |
1x Movable - Tweendeck pontoons can be used as bulkhead |
|
Main engine |
1x MaK 7M43C - 4 stroke 7 cylinder 430 x 610 mm combustion engine 6.300 kW / 8.565 hp at 500 rpm |
|
Propellers |
1x Controllable pitch propeller |
|
Boilers |
1x Thermal oil heater, exhaust heated AKV 0.75/30 1x Thermal oil heater, oil fired KOH-0,8/50 |
|
Shaft generator |
1x 600 kW |
|
Generators |
3x MAN D2840LE301 main diesel generatorsets each 400 kW |
|
Emergency generator |
1x MAN D2866LXE 20 diesel generatorset 250 kW |
|
Bow thruster |
1x 500 kW |
|
Number of holds |
2 Hold 1: 18,85 x 16,65 x 11,44 m (12,63 x 16,65 / 6,22 x 11,44) Tweendeck level: 18,85 x 16,65 / 11,44 / 4,99 (6,5 x 16,65/ 6,13 x 11,44/ 6,22 x 4,99) Tanktop: 18,85 x 11,44 / 4,99 (6,5 x 11,44 / 12,35 x 4,99) on maindeck level hold is prepared with steps according to container size; boxshaped with tweendeck: upper hold height abt. 5,53 m lower hold height abt. 4,43m Hold 2: 57,20 x 16,97 x 12,20 m Boxshaped with tweendeck Tweendeck level: Hold 1: 5,23 (from tank top) |
|
Cargo hold capacity |
Hold 1: abt.: 2.296 m³ Hold2: abt.: 10.823 m³ Total: 13.119 m³ / 463.293 ft³ |
|
Number of hatches |
2 Hatch 1: 12,63 x 16,65 /6,22 x 10,44 m Hatch 2: 57,20 x 16,97 m |
|
Hatch cover type |
No. 1 pontoon type No. 2 folding type, can be partly opened and disconnected |
|
Tweendeck |
No. 1: one complete, 6,50 x 16,15 m / 6,13 x 11,419 / 6,20 x 15,15 m No. 2: one complete, 57,20 x 16,92 m |
|
Floor space |
2.286 m² / 24.606 ft² under deck 1.245 m² / 13.401 ft² on deck |
|
Max. permitted loads |
Tanktop: abt. 16,0 t/m² On tweendeck 1: 2,5 t/m² On tweendeck 2: 3,0 t/m² On deck hold 1/2: 2,5 / 3,5 t/m² |
|
Tank capacities |
IFO abt.: 775 m³ MGO abt.: 105 m³ Ballast abt.: 3.950 m³ Freshwater abt.: 140 m³ |
|
Anchor equipment |
Length: 550,00 m Diameter: 54 mm |
|
Cargo gear |
2x NMF cranes portside: SWL 350 t 5,25-14,00 m SWL 320 t 5,25-15,00 m SWL 250 t 4,50-19,50 m SWL 200 t 4,50-24,00 m SWL 140 t 4,00-31,50 m Combinable: 700 t |
|
Accommodation |
16 persons, 16 cabins |
|
Commerical manager |
Briese Schiffahrts Gmbh & Co. Hafenstraße 12 26789 Leer Germany |
|
Manager |
Briese Heavylift GmbH & Co., KG Hafenstraße 12 26789 Leer Germany |
|
Operator |
BBC Chartering |
|
Registered owner |
Briese Schiffahrts GmbH & Co. KG MS "UTHÖRN" Care of Briese Schiffahrts GmbH & Co KG , Hafenstrasse 12 26789 Leer Germany |
|
Latest data adjustment |
03 March 2022 |
