| Westerschelde 27 June 2018 |
 |
 |
|
| Westerschelde 27/06/18 | Westerschelde 30/03/15 |
|
Name |
EEMS SOLAR |
|
Type |
General cargo ship - heavycargo |
|
IMO-number |
9559614 |
|
Call sign |
PBTJ |
|
Flag |
The Netherlands |
|
Port of registry |
Delfzijl |
|
GT |
1.862 t |
|
DWT |
Summer: 2.620 t |
|
NT |
820 t |
|
Length |
87,27 m overall 83,44 m between perpendiculars |
|
Breadth |
11,42 m |
|
Draught |
4,26 m |
|
Air draft |
8,70 m |
|
Freeboard |
1.599 mm |
|
Depth |
5,85 m |
|
Speed |
11,0 knots |
|
Built |
2010 |
|
Launch date |
02.06.2010 |
|
Date of completion |
30.07.2010 |
|
Builder |
189 One Member Limited Liability Company (189 Ship Yard) |
|
Yard number |
2600-10 |
|
Hull material |
Steel |
|
Watertight compartments |
45 |
|
Continuous decks |
1 |
|
Main engine |
1x ABC 6DZC - 4 stroke single acting 6 cylinder 256 x 310 mm diesel engine 1.104 kW / 1.500 hp at 800 rpm Built: 24.11.2009 Builder: Anglo Belgian Corporation NV Wiedauwkaai 43 9000 Gent Belgium |
|
Propellers |
1x Screw propeller controllable pitch - aft at 335 rpm |
|
Shaft generator |
1x 290 kVA - 232 kW |
|
Generators |
1x Main diesel generatorset 150 kVA - 120 kW - 204 hp |
|
Emergency generator |
1x Diesel generatorset 77 kVA - 62 kW - 95 hp |
|
Number of holds |
1 56,19 x 9,00 x 6,70 m |
|
Total capacity of holds |
Grain: 3.385 m³ / 119.500 ft³ |
|
Number of hatches |
1 56,19 x 9,00 m |
|
Hatch type |
Pontoon |
|
Max. Permitted loads |
Tanktop: 12,0 t/m² Deck: 1,6 t/m² |
|
Tank capacities |
Fuel oil: 225,78 m³ |
|
Manager |
Amasus Shipping B.V. |
|
Registered owner |
Eems Solar C.V. |
|
Latest data adjustment |
21 March 2017 |
