Westerschelde 05 June 2018 |
 |
 |
||
| Westerschelde 17/04/18 | Westerschelde 14/01/17 | ||
|
Name |
FEDERAL SHIMANTO |
|
Type |
Bulk carrier Heavy dry bulk cargo carriage - Handymax |
|
IMO-number |
9218404 |
|
Call sign |
V7VZ2 |
|
Flag |
Marshall Islands |
|
Port of registry |
Majuro |
|
Previous flags |
Republic of Panama |
|
GT |
19.125 t |
|
DWT |
Summer: 32.787 t Winter: 31.893 t |
|
NT |
10.377 t Panama: 15.976 t Suez: 19.382 t |
|
Length |
190,43 m overall 181,00 m between perpendiculars |
|
Breadth |
23,64 m extreme |
|
Draught |
10,67 |
|
Depth |
15,20 m |
|
Speed |
14,2 m knots loaded 14,5 knots ballast |
|
Built |
2001 |
|
Keel laid |
22/08/2000 |
|
Date of completion |
25/01/2001 |
|
Builder |
Shin Kurushima Toyohashi Shipbuilding Toyohashi Japan |
|
Yard number |
3527 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Bulkheads |
8 |
|
Continuous decks |
1 |
|
Main engine |
1x Mitsubishi 6UEC52LS - 2 stroke single acting 6 cylinder 520 x 1.600 mm combustion engine 7.080 kW / 9.600 bhp at 133 rpm Builder: Mitsubishi Heavy Industries, Ltd., Kobe Shipyard & Machinery Works - Japan |
|
Propeller shaft |
1x Oil lubrication shaft without monitoring device Diameter: 510 mm |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Auxiliary boiler, composite - 6,9 bar Evaporation: 4,00 t/h Builder: Tortoise Engineering Co., Ltd. |
|
Generators |
3x Daihatsu 3DK(M)-20 main diesel generatorsets Builder: Daihatsu Diesel Mfg. Co., Ltd. Moriyama Factory |
|
Emergency generator |
1x Mitsui F6L912 diesel generatorset |
|
Bow thruster |
1x 645 kW |
|
Number of holds |
6 Hold 1:6,52 / 18,00 m Hold 2: 18,00 / 18,00 m Hold 3:18,00 / 18,00 m Hold 4:18,00 / 18,00 m hold 5:18,00 / 18,00 m Hold 6:18,0 / 6,52 m |
|
Cargo hold capacity |
Grain - Bale Hold 1: 7.525 m³- 7.049 m³ Hold 2: 6.737 m³- 6.479 m³ Hold 3: 6.728 m³- 6.481 m³ Hold 4: 6.012 m³- 5.781 m³ Hold 5: 7.397 m³- 7.138 m³ Hold 6: 6.117 m³- 5.950 m³ Total: 40.516 m³ - 38.856 m³ |
|
Number of hatches |
6 Hatch 1: 16,80 x 12,90 m Hatch 2: 18,40 x 12,90 m Hatch 3: 18,40 x 12,90 m Hatch 4: 16,00 x 12,90 m Hatch 5: 20,00 x 12,90 m Hatch 6: 16,80 x 12,90 m |
|
Hatch cover type |
Folding hydraulic |
|
Max? Permitted loads |
Tanktop: 22,0 t/m² |
|
Tank capacities |
Ballast: 12.229 m³ Fuel oil: 1.116 m³ Fresh water: 471 m³ MGO: 455 m³ |
|
Anchor equipment |
Length: 577,50 m Diameter: 60 mm |
|
Cargo gear |
3x Electro-hydraulic deck cranes - SWL 30,0t each |
|
Commercial manager |
FEDNAV Group 1000 de La Gauchetière Street West, Suite 3500 Montreal Quebec H3B 4W5 Canada |
|
ISM manager |
Anglo-Eastern Ship Management Ltd. 17th Floor, Kingston International Centre, 19, Wang Chiu Road, Kowloon Bay, Kowloon Hong Kong China |
|
Registered owner |
Baffin Investments Limited Care of FEDNAV Ltd , Suite 3500 1000, rue de la Gauchetiere O Montreal QC H3B 4W5 Canada |
|
Latest data adjustment |
16 November 2022 |
