Westerschelde 36 September 2018 |
 |
 |
 |
 |
 |
||||
| Westerschelde 08/01/19 | Westerschelde 014/01/17 | Westerschelde 14/01/17 | Westerschelde 14/01/17 | Vlissingen 19/05/16 | ||||
|
Name |
OSTBORG |
|
Previous names |
01/2001 - 02/2006 Rufinia 02/2006 - 03/2015 Ostgard |
|
Type |
General cargo / Container ship - Heavycargo - Single decker - Open hatch |
|
IMO-number |
9196216 |
|
Call sign |
PBAW |
|
Flag |
The Netherlands |
|
Port of registry |
Delfzijl |
|
Previous flags |
01/2001 - 06/2006 The Netherlands, Farmsum - Call sign: PBAW 06/2006 - 03/2015 The Netherlands, Rotterdam - Call sign: PBAW |
|
GT |
2.868 t |
|
DWT |
Summer: 3.792 t |
|
DWCC |
Summer: 3.590 t |
|
NT |
1.613 t |
|
Number of 20ft containers |
In hold: 96 On deck: 88 Total: 184 |
|
Length |
89,25 m overall 84,60 m between perpendiculars |
|
Breadth |
13,30 m |
|
Draught |
Summer: 5,67 m Winter: 5,56 m |
|
Air draft |
29,00 m in ballast |
|
Depth |
7,15 m moulded |
|
Speed |
12,5 knots |
|
Built |
2001 |
|
Launch date |
02/12/2000 |
|
Date of completion |
05/01/2001 |
|
Builder |
Scheepswerf Peters B.V. Kampen The Netherlands |
|
Yard number |
467 |
|
Hull material |
shipbuilding steel (standard) |
|
Hull type |
Double skinned |
|
Watertight compartments |
5 |
|
Movable bulkheads |
2 |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 6M20 - 4 stroke single acting 6 cylinder 255 x 400 mm combustion engine 1.800 kW / 2.445 hp at 750 rpm Built: 28/09/2000 Builder: Caterpillar Motoren GmbH & Co. KG, Kiel - Germany |
|
Propellers |
1x Screw propeller controllable pitch - aft at 217 rpm |
|
Electric installations |
Power voltage: 400 V Lighting voltage: 230 V Frequency: 50 Hz |
|
Shaft generator |
1x 530 kVA - 424 kW |
|
Generators |
1x Sisu Diesel 612 DSBG main diesel generatorset 320 kVA - 256 kW - 374 hp |
|
Emergency generator |
1x Sisu Diesel 420 DSG diesel generatorset 80 kVA - 64 kW - 95 hp |
|
Bow thruster |
1x 370 kW |
|
Number of holds |
1x Box shaped 62,40 x 11,16 x 8,85 m |
|
Total capacity of holds |
5.833 m³ / 205.090 m³ |
|
Hold ventilation |
Electrical ventilation 6 air changes per hour, basis empty hold Vessel is not fitted with dehumidifier system |
|
Cargo hatchways |
11 1x 1,90 x 11,40 m 10x 6,10 x 11,40 m |
|
Hatch type |
Coops & Nieborg pontoon hatches |
|
Tank capacities |
MGO: 295 m³ Water ballast: 1.515 m³ Fresh water: 40 m³ |
|
Anchor equipment |
3x Anchors weight each 1.920 kg Length: 440,00 m |
|
Crew size |
10 |
|
ISM & commercial manager |
Wagenborg Shipping B.V. Marktstraat 10 9934 CK Delfzijl The Netherlands |
|
Previous managers |
01/2001 - 06/2006 Flagship Management B.V., Farmsum - The Netherlands 06/2006 - 03/2015 Bore Shipowners B.V., Rotterdam - The Netherlands |
|
Registered owner |
Scheepvaartonderneming Ostborg B.V. Care of Wagenborg Shipping BV Marktstraat 10 9934 CK Delfzijl The Netherlands |
|
Previous names & owners |
01/2001 - 06/2006 Rufunia - C.V. Scheepvaartonderneming Rufinia, Delfzijl - The Netherlands 06/2006 - 03/2015 Ostgard - Bore Ostgard B.V., Rotterdam - The Netherlands |
|
Latest data adjustment |
14 August 2022 |
