Antwerpen 10 May 2017 |
 |
 |
|
| Antwerpen 10/05/17 | Antwerpen 16/02/18 |
|
Name |
BF TIMARU |
|
Previous names |
2006 built as: Team Spirit 11.2006 - 07.2011 Normed Bremen 07.2011 - 07.2012 Team Bremen |
|
Type |
General cargo ship - Designed for carriage of containers - Box Shaped Tweendecker |
|
IMO-number |
9346421 |
|
Call sign |
CQED |
|
Flag |
Portugal |
|
Port of registry |
Madeira |
|
GT |
8.407 t registered |
|
DWT |
Summer: 11.142 t |
|
NT |
4.215 t registered |
|
Number of 20ft containers |
In hold: 272 On deck: 400 Total: 672 |
|
Number of 40ft containers |
In hold: 116 On deck: 186 Total: 302 |
|
Container capacity 14t |
370 |
|
Reefer plugs |
30 on deck |
|
Length |
129,36 m overall 120,60 m between perpendiculars |
|
Breadth |
19,00 m moulded |
|
Draught |
Summer: 8,71 m |
|
Moulded L x B x D |
121,32 x 19,00 x 11,65 m |
|
Registered L x B x D |
121,32 x 19,00 x 11,65 m |
|
Height keel to top mast |
37,90 m |
|
Freeboard |
Summer: 2.960 mm |
|
Depth |
11,65 m moulded to main deck |
|
Speed |
Service: 14,5 knots Max.: 16,5 knots |
|
Built |
2006 |
|
Keel laid |
06.11.2005 |
|
Launch date |
24.08.2006 |
|
Date of completion |
29.11.2006 |
|
Builder |
Daehan Shipbuilding Co. Ltd. |
|
Yard number |
H506 |
|
Hull material |
Steel |
|
Main engine |
1x MaK 6M43 - 4 stroke single acting 6 cylinder diesel engine 6.000 kW at 500 rpm Manufacturer: Caterpillar Motoren Gmbh & Co. KG - Germany |
|
Propeller shaft |
1x Oil lubrication shaft without monitoring device |
|
Propellers |
1x Controllable pitch propeller |
|
Boilers |
1x Auxiliary vertical boiler - 8,8 bar |
|
Shaft generator |
700 kW |
|
Generators |
3x Main diesel generatorsets each 400 kW |
|
Emergency generator |
1x Diesel generatorset 112 kW |
|
Bow thruster |
1x 500 kW |
|
Number of holds |
2 Hold 1: Capacity without tweendeck: 2.562 m³ / 9.0462 ft³ Dimensions: 18,87 x 15,57 x 13,60 m Clearance under/above tw. deck: 6,00 m/6,80 m Hold 2: Capacity without tweendeck: 11.004 m³ / 388.592 ft³ Dimensions: 58,19 x 15,57x 12,00 m Clearance under/above tw. deck: Lower pos.: 5,35 m/5,85 m Upper pos.: 7,90 m/3,30 m |
|
Weather deck |
Forward hatch dimensions: 18,87 x 15,57 m Aft hatch dimensions: 58,19 x 15,57 m Total loading area: 3.003 m² |
|
Deck loads |
Tanktop: 18,0 t/m² Tweendeck: 4,0 t/m² Weatherdeck: 2,5 t/m² Hatch covers: 2,0 t/m² |
|
Hatchcovers/Tweendecks |
Type of hatchcovers: Pontoon hatches Tweendeck pontoons: 3 removable in hold 1 9 removable in hold 2 Removable bulkheads: Made of two TD pontoons in two positions in hold 2 |
|
Tank capacities |
HFO: 844 m³ MGO: 140 m³ Fresh water: 153 m³ Ballast water: 4.400 m³ |
|
Cargo gear |
2x Liebherr in port side cranes - SWL 60 t combinable to 120 t |
|
Crew size |
14 |
|
Manager |
Coral Shipmanagement GmbH & Co. KG |
|
Operator |
Reederei Foroohari |
|
Registered owner |
MS "BF Timaru" Schiffahrts GmbH & Co. KG |
|
Latest data adjustment |
27 May 2017 |
