Name |
COLOMBIAN STAR |
|
Type |
Refrigerated cargo ship - Equipped for carriage of containers |
|
IMO-number |
9172480 |
|
Call sign |
A8SL3 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
Previous flags |
Republic of Panama, Panama City - Call sign: 3FQG8 |
|
GT |
15.292 t Suez: 16.083,63 t |
|
DWT |
Summer: 14.814,9 t on 9,06 m draft |
|
NT |
7.414 t Panama: 13.095 t Suez: 13.888,99 t |
|
Displacement |
Summer: 24.454 t |
|
Number of 20ft containers |
On hatch cover: 105 On deck: 119 Under deck: 48 Container hold: 96 Total: 368 |
|
Number of 40ft containers |
On hatch cover: 76 On deck: 60 Under deck: 6 Container hold: 48 Total: 190 |
|
Container capacity 14t |
184 |
|
Length |
184,80 m overall 175,40 m between perpendiculars |
|
Breadth |
24,00 m extreme |
|
Draught |
9,07 m |
|
Air draft |
32,03 m in ballast |
|
Freeboard |
4.295 mm |
|
Depth |
13,30 m |
|
Speed |
Max.: 21,4 knots 19 knots banana laden |
|
Built |
1998 Rebuild: 2014 |
|
Keel laid |
28/01/1998 |
|
Launch date |
11/05/1998 |
|
Date of completion |
06/08/1998 |
|
Builder |
Shikoku Dockyard Takamatsu Japan |
|
Yard number |
888 |
|
Hull material |
Steel |
|
Main engine |
1x Mitsui/MAN-B&W 6L60MC - 2 stroke 6 cylinder 600 x 2.292 mm combustion engine 12.268 kW / 16.669 hp at 105,0 rpm Built: 01/10/1997 Builder: Mitsui Engineering & Shipbuilding Co., Ltd. - Japan |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x CHM Aalborg 135,00 m² - 0,9 bar |
|
Generators |
4x Main diesel generatorsets each 1.000 kVA - 800 kW - 1.223 hp 1x Main diesel generatorset 2.850 kVA - 2.280 kW - 3.261 hp |
|
Emergency generator |
1x Diesel generatorset 80 kVA - 64 kW - 111 hp |
|
Number of cargo holds |
5 |
|
Cargo hold capacity |
37.427,8 m³ / 566.554 ft³ |
|
Hold ventilation |
90 Air circulations per hour 2 Air renewals per hour |
|
Number of hatches |
5 |
|
Compartment square metres |
6.536,8 m² |
|
Temp. compartments / zones |
18 / 8 |
|
Controlled atmosphere zones |
8 |
|
Total pallets |
5.134 t |
|
Temperature range |
+15° -25° Celsius |
|
Tank capacities |
Fuel oil: 2.029,4 m³ |
|
Cargo gear |
2x Hydraulic cranes - SWL 37,0 t 1x Luffing crane with cargo turner - SWL 45 t 3x Side loading system - SWL 12,5 t (8 pallets per lift) |
|
Manager |
Africa Express line |
|
ISM manager |
Compagnie Fruitiere |
|
Operator |
Star Reefers Poland Sp. z o.o. Poland |
|
Registered owner |
SSI Shipowning I Inc. Care of Star Reefers UK LtD. 30 Charles II Street, St. James’s Square London United Kingdom |
|
Latest data adjustment |
12 November 2021 |
