Westerschelde 25 April 2017 |
 |
 |
 |
 |
 |
||||
| Westerschelde 03/07/16 | Westerschelde 22/11/17 | Westerschelde 03/01/18 | Westerschelde 03/01/18 | Westerschelde 18/08/16 | ||||
|
Name |
ELSEBETH |
|
Type |
Refrigerated cargo ship - Equipped for carriage of containers |
|
IMO-number |
9175901 |
|
Call sign |
5VFR9 |
|
Flag |
Togo |
|
Port of registry |
Lomé |
|
Previous flags |
|
|
GT |
10.519 t |
|
DWT |
Summer: 12.734 t |
|
NT |
5.406 t Panama Canal: 9.073 t Suez Canal: 9.078,59 t |
|
Number of 20ft containers |
212 |
|
Reefer plugs |
106 |
|
Length |
151,99 m overall 139,40 m between perpendiculars |
|
Breadth |
23,00 m |
|
Draft |
Summer: 9,67 m |
|
Freeboard |
3.333 mm |
|
Depth |
13,00 m |
|
Speed |
21,0 knots |
|
Built |
1998 |
|
Date of completion |
24/02/1998 |
|
Builder |
Iwagi Zosen Co., Ltd. Kamijima Japan |
|
Yard number |
S-Z178 |
|
Hull material |
Steel |
|
Watertight compartments |
7 |
|
Continuous decks |
3 |
|
Main engine |
1x Mitsubishi 6UEC60LSII - 2 stroke single acting 6 cylinder 600 x 2.300 mm combustion engine 11.915 kW / 16.189 bhp at 105 rpm Build: 1997 Manufacturer: Akasaka Diesels Limited, Yaizu - Japan |
|
Propellers |
1x Screw propeller solid - aft at 105 rpm |
|
Boilers |
1x CHR Miura 345,90 m² - 12,0 bar 1x CHO Miura 17,90 m² - 8,0 bar |
|
Electric installations |
Power voltage: 440 V Lighting voltage: 230 V Frequency: 60 Hz |
|
Generators |
2x Diesel generatorsets each 625 kVA - 500 kW - 750 hp |
|
Emergency generator |
1x Diesel generatorset 60 kVA - 48 kW - 82 hp |
|
Number of holds |
4 |
|
Total hold capacity |
15.531 m³ / 549.326 ft³ |
|
Number of hatches |
4 13,60 x 7,85 m each |
|
Compartments |
16 |
|
Temperature zones |
8 |
|
Temperature range |
-30/+15°C |
|
Minimum deck height |
2,20 m |
|
Air circulations |
90x p/h |
|
Air renewals |
4x p/h |
|
Pallets |
6.637 |
|
Tank capacities 100% |
Ballast: 1.701,7 m³ IFO: 1.718 m³ MGO: 104 m³ |
|
Cargo gear |
2x Cranes - SWL 8,0 t each 2x Cranes - SWL 36,0 t each |
|
Crew |
25 |
|
Manager |
Swedisch Management Co. S.A. Amro Street Dubai United Arab Emirates |
|
Previous managers |
1998 - 2003 United Ocean Ship Management Pte. Ltd. 2003 - 2006 Seatrade Groningen B.V., Groningen - The Netherlands 2006 - 2018 Triton Schiffahrts GmbH & Co. KG, Leer - Germany |
|
Registered owner |
Miracle Navigation Inc. Dubai United Arab Emirates |
|
Previous names & owners |
1998 - 2003 Elsebeth - United Reefer Carriers S.A. 2003 - 2007 Elsebeth - B.V. Shipping Company Elsebeth, Groningen - The Netherlands 2007 - 2018 Elsebeth - Schiffahrtsgesellschaft Elsebeth, Leer - Germany |
|
Renamed |
01/2022 Cattle Force Rebuild: Livestock Carrier Togo, Lomé - Call sign: 5VFR9 |
|
Latest data adjustment |
05 March 2023 |
