Westerschelde 25 July 2017 |
 |
 |
 |
 |
|||
| Brugge 23/07/22 | Brugge 23/07/22 | Brugge 23/07/22 | Brugge 23/07/22 |
|
Name |
ARKLOW VANGUARD |
|
Type |
Multi-Purpose general cargo ship - heavycargo Bottom strengthened for loading aground - Tank top strengthened for heavy cargoes |
|
IMO-number |
9772577 |
|
Call sign |
PDAY |
|
Flag |
The Netherlands |
|
Port of registry |
Rotterdam |
|
GT |
2.999 t |
|
DWT |
5.168 t |
|
NT |
1.731 t |
|
Length |
86,93 m overall 84,98 m between perpendiculars |
|
Breadth |
15,00 m moulded |
|
Draught |
Summer: 6,35 m |
|
Air draft |
Min.: 18,25 m |
|
Freeboard |
830 mm |
|
Depth |
7,17 m moulded |
|
Speed |
Max.: 12,5 knots |
|
Built |
2017 |
|
Launch date |
31/03/2017 |
|
Date of completion |
08/05/2017 |
|
Builder |
Royal Bodewes Shipyard Hoogezand The Netherlands |
|
Yard number |
726 |
|
Hull material |
Steel |
|
Movable bulkheads |
Portable bulkhead may be placed in 8 positions for cargo separation and storage position |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 6M25 - 4 stroke single acting 6 cylinder 255 x 400 mm combustion engine 1.740 kW / 2.364 hp at 720 rpm Built: 14/07/2016 Builder: Caterpillar Motoren GmbH & Co. KG, Anqing - China |
|
Propellers |
1x Screw propeller controllable pitch - aft at 140 rpm |
|
Shaft generator |
1x 435 kVA - 348 kW |
|
Generators |
2x Sisu main diesel generatorsets each 192 kVA - 154 kW - 224 hp at 1.500 rpm |
|
Emergency generator |
1x Sisu diesel generatorset 81 kVA - 65 kW - 101 HP |
|
Bow thruster |
1x Electric bow thruster 300 kW |
|
Number of holds |
1 |
|
Total capacity of holds |
Bale 6.258 m³ - 221.000 ft³ Grain: 6.258 m³ |
|
Hatches type |
Coops & Nieborg pontoon system |
|
Max. permitted loads |
Hatch top: 1,75 t/m² Tank top: 15,0 t/m² |
|
Tank capacities |
Fuel oil: 210,05 m³ Ballast: 1.870 m³ HFO: 109 m³ Gas oil: 95 m³ Fresh water: 32 m³ Lub oil: 11 m³ |
|
Manager |
Arklow Shipping Nederland B.V. Hoofdweg 18 3067 GH Rotterdam The Netherlands |
|
Owner |
Avoca Shipping B.V. Hoofdweg 18 3067 GH Rotterdam The Netherlands |
|
Registered owner |
Ferrybank Shipping B.V., Rotterdam - The Netherlands Care of Arklow Shipping Unlimited Co (Arklow Shipping ULC), North Quay, Arklow, Co Wicklow Ireland |
|
Latest data adjustment |
27 July 2022 |
