Westerschelde 04 October 2017 |
 |
| Westerschelde 04/01/17 |
|
Name |
SCOTER |
|
Type |
Bulk carrier - Supermax |
|
IMO-number |
9594420 |
|
Call sign |
5BFS3 |
|
Flag |
Cyprus |
|
Port of registry |
Limassol |
|
GT |
33.042 t |
|
DWT |
Summer: 56.880 t |
|
NT |
19.132 t |
|
Length |
189,89 m overall 185,00 m between perpendiculars |
|
Breadth |
32,28 m extreme |
|
Draught |
12,80 m |
|
Air draft |
39,55 m (Without holds flooded but fully ballasted) |
|
Depth |
18,00 m |
|
Speed |
14,2 knots |
|
Built |
2012 |
|
Keel laid |
01.11.2010 |
|
Launch date |
17.02.2011 |
|
Date of completion |
07.05.2011 |
|
Builder |
Yangfan Group Co., Ltd. |
|
Yard number |
H-2149 |
|
Hull material |
Steel |
|
Main engine |
1x Man B&W 6S50MC-C8-TII - 6 cylinder diesel engine 12.712 hp at 127 rpm |
|
Boilers |
1x Auxiliary boiler, composite |
|
Generators |
3x Yanmar 6EY18AL main diesel generatorsets |
|
Emergency generator |
1x Sisu Diesel 634 DSBG diesel generatorset |
|
Number of holds |
5 Hold 1: 27,88 x 10,70 FWD / 23,82 m aft Hold 2: 28,70 x 23,82 m Hold 3: 27,60 x 23,82 m Hold 4: 27,78 x 23,82 m Hold 5: 27,60 x 23,82 m FWD / 9,06 m aft |
|
Cargo hold capacity |
Grain / Bale: Hold 1: 13.009,9 / 12.300 m³ Hold 2: 15.333,3 / 14.700 m³ Hold 3: 14.553,1 / 14.000 m³ Hold 4: 15.333,3 / 14.700 m³ Hold 5: 13.404,6 / 12.500 m³ Total: 71.634,2 / 68.200 m³ |
|
Number of hatches |
5 Hatch 1: 18,86 x 18,26 m Hatch 2: 21,32 x 18,26 m Hatch 3: 21,32 x 18,26 m Hatch 4: 21,32 x 18,26 m Hatch 5: 21,32 x 18,26 m |
|
Hatches type |
MacGregor high stowing & folding, operated by external hydraulic cylinders |
|
Tank capacities |
Ballast: 30.855,9 m³ |
|
Anchor equipment |
Length: 622,32 m Diameter: 73 mm |
|
Cargo gear |
4x Cranes - SWL 36,0 t each with 4 grabs each 12 m³ |
|
Manager |
Navarone S.A. |
|
Registered owner |
Andria Shipping Ltd. Nicosia, 1070 Cyprus |
|
Latest data adjustment |
11 December 2017 |
