Westerschelde 08 August 2018 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 25/11/17 | Antwerpen 16/02/18 | Antwerpen 21/02/19 | Antwerpen 21/02/19 | Antwerpen 21/02/19 | Antwerpen 31/12/19 |
 |
| Westerschelde 30/12/19 |
|
Name |
SEVKETTIN SONAY |
|
Type |
General cargo ship - Equipped for carriage of containers |
|
IMO-number |
9334313 |
|
Call sign |
3FRL8 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
Previous flags |
Turkey, Istanbul - Call sign: TCPK8 |
|
GT |
9.490 t |
|
DWT |
14.888,83 t |
|
NT |
4.640 t |
|
Displacement |
19.676,93 t |
|
Number of 20ft containers |
On hatch cover: 304 |
|
Length |
143,41 m overall 134,00 m between perpendiculars |
|
Breadth |
21,70 m |
|
Draught |
9,01 m |
|
Air draft |
31,50 m |
|
Freeboard |
2.120 mm |
|
Depth |
11,10 m moulded |
|
Speed |
14,5 knots |
|
Built |
2006 |
|
Keel laid |
03/12/2004 |
|
Date of completion |
29/08/2006 |
|
Builder |
Celiktekne Tersanesi San. VE TIC. A.S. Turkey |
|
Yard number |
NB59 |
|
Hull material |
Special steel |
|
Watertight compartments |
10 |
|
Continuous decks |
1 |
|
Main engine |
1x MAN-B&W 6S35MC Mk-7 - 2 stroke 6 cylinder 350 x 1.400 mm Combustion engine 4.440 kW / 6.033 hp at 173 rpm Built: 2005 Builder: MAN B & W Diesel A/S Alpha Diesel, Frederikshavn - Denmark |
|
Propellers |
1x Screw propeller controllable pitch- aft at 173 rpm |
|
Boilers |
1x CHR Aalborg 85,40 m² - 10,0 bar 1x CHO Aalborg 19,00 m² - 12,6 bar |
|
Electric installations |
Power voltage: 400 V Lighting voltage: 220 V Frequency: 50 Hz |
|
Shaft generator |
1x Lerroy Sommer 750 kVA - 600 kW - 50Hz at 1.500 rpm |
|
Generators |
3x MAN Lindenberg main diesel generatorsets each 400 kVA - 320 kW - 469 hp at 1.500 rpm - 400 Volt 50 Hz |
|
Emergency generator |
1x MAN Lindenberg diesel generatorset 125 kVA - 100 kW - 150 hp at 1.500 rpm 400 Volt 50 Hz |
|
Bow thruster |
1x Schottel STT 330 T-LK - 450 kW |
|
Number of holds |
4x Double skin & “Box shape” type Hold 1: Box Shape 12,60 x12,06 m – 1.655,62 m³ – Inner Bottom with max. Area of 40 m² Hold 2: Box Shape 25,60 x 17,20 m – 5.310,78 m³ -Inner Bottom with max. Area of 225 m² Hold 3: Box Shape 25,60 x17,20 m – 5.352,36 m³ -Inner Bottom with max. Area of 225 m² Hold 4: Box Shape 19,20 x 17,20 m – 4.060,20m³ -Inner Bottom with max. Area of 225 m² |
|
Total capacity of holds |
16.910 m³ including hatch coamings |
|
Hatch covers type |
Hydraulic operated, Folding type |
|
Hatch cover strength |
1,75 t/m² |
|
Tank capacities |
Fuel oil: 728 m³ Diesel oil: 268 m³ Fresh water: 143 m³ Ballast: 5.386 m³ |
|
Cargo gear |
3x NMF PKL 330 piston type cranes - SWL 30,0 t each Outreach: 22,00 m |
|
Manager |
AY Denizcilik A.S. |
|
Operator |
Sonay Shipping Istasyon Mah. D-100 Karayolu Cad. Hacıoğulları Plaza No: 50 34940 Tuzla-Istanbul Turkey |
|
Owner |
AY Denizcilik A.S. Istasyon Mah. D-100 Karayolu Cad. Hacıoğulları Plaza No: 50 34940 Tuzla-Istanbul Turkey |
|
Latest data adjustment |
06 June 2020 |
