Westerschelde 11 November 2017 |
|
Name |
PORT SHANGHAI |
|
Type |
Bulk carrier |
|
IMO-number |
9423528 |
|
Call sign |
3FXF3 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
32.415 t registered |
|
DWT |
Summer: 58.747 t |
|
NT |
19.353 t registered |
|
Length |
189,99 m overall 185,75 m between perpendiculars |
|
Breadth |
32,26 m moulded |
|
Draught |
12,82 m |
|
Freeboard |
5.266 mm |
|
Depth |
18,00 m |
|
Speed |
14,2 knots |
|
Built |
2009 |
|
Keel laid |
28/06/2006 |
|
Delivery date |
16/01/2009 |
|
Builder |
Portline Transportes Maritimos Internacionais SA |
|
Yard number |
SS-027 |
|
Hull material |
Steel |
|
Bulkheads |
Water tight: 2 Oil tight: 4 |
|
Main engine |
1x 6S50MC-C - 6 cylinder 500 x 1.900 mm combustion engine 8.400 kW Manufacturer: Mitsui Engineering & Shipbuilding Co., Ltd. |
|
Propellers |
1 |
|
Boilers |
1x Vertical composite boiler - 7,0 bar Manufacturer: Osaka Boiler Mfg. Co., Ltd. |
|
Generators |
3x Main diesel generatorsets each 480 kW |
|
Number of holds |
5 |
|
Hold capacity |
Grain: 72.360 m³ |
|
Number of tanks |
Ballast: 22 Fuel oil: 6 Lubricating oil: 3 Fresh water: 3 Waste water: 2 Diesel oil: 2 Sludge: 2 Chain: 1 |
|
Tank capacities 100% |
Diesel Oil: 206,3 m³ / 185,67 t Freshwater: 326,5 m³ Fuel Oil: 2.612,9 m³ / 2.560,64 t Lube Oil: 57,6 m³ / 51,84 t |
|
Cargo gear |
4x Cranes - SWL 30,0 t each |
|
Operator |
Otani Shipping Inc. |
|
Registered owner |
Otani Shipping Inc. |
|
Latest data adjustment |
20 May 2018 |
