Westerschelde 30 August 2016 |
 |
|
| Westerschelde 24/11/18 | |
|
Name |
KINNE |
|
Type |
General cargo ship / Container ship |
|
IMO-number |
9306689 |
|
Call sign |
PHAR |
|
Flag |
The Netherlands |
|
Port of registry |
Delfzijl |
|
GT |
2.810 t |
|
DWT |
Summer: 4.765 t |
|
NT |
1.652 t |
|
Light ship |
1.127 t |
|
Length |
89,00 m overall 84,99 m between perpendiculars |
|
Breadth |
13,35 m |
|
Draught |
Summer: 5,85 m |
|
Freeboard |
1.655 mm |
|
Depth |
7,50 m moulded |
|
Speed |
10,5 knots laden 11,5 knots ballast 8,5 knots economic |
|
Built |
2004 |
|
Keel laid |
27/08/2003 |
|
Launch date |
24/04/2004 |
|
Date of completion |
04/06/2004 |
|
Builder |
Scheepswerf Ferus Smit B.V. Westerbroek The Netherlands |
|
Yard number |
356 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Watertight compartments |
6 |
|
Continuous decks |
1 |
|
Main engine |
1x Wärtsilä 6L26A - 4 stroke single acting 6 cylinder 260 x 320 mm combustion engine 1.850 kW / 2.527 hp at 900 rpm Built: 2003 Builder Wärtsilä Italia S.p.A. , Trieste - Italy |
|
Propellers |
1x Screw propeller controllable pitch 4 blades |
|
Electric installations |
Power voltage: 440 V Lighting voltage: 230 V Frequency: 60 Hz |
|
Shaft generator |
1x Stamford 406 kVA - 325 kW |
|
Generators |
1x Scania main diesel generatorset 219 kVA - 175 kW - 254 hp |
|
Emergency generator |
1x Sissu diesel generatorset 97 kVA - 78 kW - 115 hp |
|
Bow thruster |
1x Jastram 270 kW |
|
Number of holds |
2x box shaped |
|
Cargo hold capacity |
Grain: 5.097 m³ |
|
Number of hatches |
2 Hatch 1: 22,10 x 10,40 m Hatch 2: 39,60 x 10,40 m |
|
Hatch type |
9 Pontoons with 1 hatch cover crane |
|
Max permitted loads |
Tanktop: 10,0 t/m² Hatch covers: 1,3 t/m² |
|
Tank capacities |
HFO: 210,95 m³ MDO: 36,55 m³ Fresh water: 37 m³ Water ballast: 1.737 m³ |
|
Manager |
Marin Ship Management B.V., Hogelandsterweg 14 9936 BH Farmsum The Netherlands |
|
Owner |
Ocean Sun B.V. Delfzijl The Netherlands |
|
Latest data adjustment |
26 April 2024 |
