Westerschelde 14 April 2017 |
 |
 |
 |
||
| Westerschelde 20/05/17 | Westerschelde 30/05/17 | Vlissigen 25/02/16 | ||
|
Name |
SYDBORG |
|
Previous names |
10/2000 - 09/2003 Polar Snow 09/2003 - 05/2006 Griend 05/2006 - 06/2015 Sydgard |
|
Type |
Cargo / Container ship - Open hatch, fully box, double skinned Single decker |
|
IMO-number |
9196204 |
|
Call sign |
PFBD |
|
Flag |
The Netherlands |
|
Port of registry |
Delfzijl |
|
Previous flags |
01/2000 - 06/2006 The Netherlands, Terschelling - Call sign: PFBD 06/2006 - 06/2015 The Netherlands, Rotterdam - Call sign: PFBD |
|
GT |
2.868 t |
|
DWT |
Summer: 3.780 t |
|
DWCC |
Summer: 3.950 t |
|
NT |
1.613 t |
|
Number of 20ft containers |
In hold: 96 On deck: 88 Total: 184 |
|
Length |
89,25 m overall 84,60 m between perpendiculars |
|
Breadth |
13,30 m |
|
Draught |
Summer: 5,68 m Winter: 5,56 m |
|
Air draft |
29,00 m in ballast |
|
Freeboard |
1.191 mm |
|
Depth |
7,15 m moulded |
|
Speed |
Max: 12,5 knots Service: 10,5 knots |
|
Built |
2000 |
|
Launch date |
09/09/2000 |
|
Delivery date |
07/10/2000 |
|
Builder |
Scheepswerf Peters B.V. Kampen The Netherlands |
|
Yard number |
466 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Double bottom |
|
Watertight bulkheads |
5 |
|
Movable bulkheads |
2 |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 6M25 - 4 stroke 6 single acting cylinder 255 x 400 mm combustion engine 1.800 kW / 2.445 hp at 750 rpm Built: 06/07/2000 Builder: MaK Motoren GmbH & Co. KG, Kiel - Germany |
|
Propellers |
1x Screw propeller controllable pitch aft at 217 rpm |
|
Electric installations |
Power voltage: 400 V Lighting voltage: 220 V Frequency: 50 Hz |
|
Shaft generator |
1x 530 kVA - 424 kW |
|
Generators |
1x Sisu Diesel 612 DSBG main diesel generatorset 320 kVA - 256 kW - 374 hp |
|
Emergency generator |
1x Sisu Diesel 420 DSG diesel generatorset 77 kVA - 62 kW - 95 hp |
|
Bow thruster |
250 kW |
|
Number of holds |
1xBox shaped 62,95 x 11,16 x 8,85 m |
|
Cargo hold capacity |
Grain/bale: 5.829 m³ / 205.090 ft³ |
|
Hold ventilation |
Electrical ventilaton hold ventilation abt 6 air changes per hour, basis empty hold Hold is fitted with dehumidifier system |
|
Number of hatches |
1 62,95 x 11,16 m |
|
Hatch type |
Coops & Nieborg pontoon hatches |
|
Tank capacities |
MGO: 295 m³ Water ballast: 1.515 m³ Fresh water: 40 m³ |
|
Anchor equipment |
3x Anchors weight each 1.920 kg Chain length: 440,00 m |
|
Crew size |
10 |
|
Manager |
Wagenborg Shipping BV Marktstraat 10 9934 CK Delfzijl The Netherlands |
|
Previous managers |
10/2000 - 09/2003 Amasus Shipping B.V., Delfzijl - The Netherlands 09/2003 - 05/2006 Poseidon Chartering B.V., Delfzijl - The Netherlands 05/2006 - 05/06/2015 Bore Shipowners B.V., Rotterdam - The Netherlands |
|
Registered owner |
Scheepvaartonderneming Sydborg B.V. The Netherlands |
|
Previous names & owners |
10/2000 - 09/2003 Polar Snow - C.V. Scheepvaartonderneming Polar Snow, Terschelling - The Netherlands 09/2003 - 05/2006 Griend - Scheepvaartonderneming Polar Snow, Terschelling - The Netherlands 05/2006 - 06/2015 Sydgard - Bore Sydgard B.V., Rotterdam - The Netherlands |
|
Latest data adjustment |
27 July 2023 |
