Westerschelde 25 February 2019 |
 |
 |
|
| Westerschelde 11/10/15 | Westerschelde 17/02/19 |
|
Name |
NORD TITAN |
|
Type |
Bulk carrier - Strengthened for heavy cargo loading |
|
IMO-number |
9701164 |
|
Call sign |
9V6239 |
|
Flag |
Republic of Singapore |
|
Port of registry |
Singapore City |
|
Previous flag |
2014 - 02/2019 Republic of Panama, Panama City - Call sign: 3EML9 |
|
GT |
40.937 t registered |
|
DWT |
77.095 t |
|
NT |
25.984 t registered |
|
Length |
224,98 m overall |
|
Breadth |
32,24 m moulded |
|
Draught |
Max: 15,30 m |
|
Moulded L x B x D |
218,00 x 32,24 x 19,90 m |
|
Registered L x B x D |
218,63 x 32,24 x 19,90 m |
|
Freeboard |
Summer: 5.502 mm |
|
Depth |
19,90 m moulded |
|
Speed |
Max: 15,0 knots |
|
Built |
2014 |
|
Keel laid |
04/03/2014 |
|
Launch date |
11/06/2014 |
|
Date of completion |
06/08/2014 |
|
Builder |
Imabari Shipbuilding Co., Ltd. Marugame Headquarters |
|
Yard number |
1668 |
|
Hull material |
Steel |
|
Main engine |
1x 2 stroke single acting 6 cylinder 600 x 2.400 mm combustion engine 8.330 kW at 80,5 rpm Manufacturer: Hitachi Zosen Corporation Ariake Works |
|
Propeller shaft |
1x Oil lubrication shaft with monitoring device Diameter: 550 mm |
|
Propellers |
1 |
|
Boilers |
1x Auxiliary vertical boiler - 8,0 bar Evaporation: 3,00 t/h Manufacturer: MIURA Co., Ltd. |
|
Generators |
4x Generators total 1.800 kVA |
|
Number of holds |
7 |
|
Cargo hold capacity |
Grain: 91.140 m³ |
|
Number of hatches |
7 |
|
Tank capacities |
Fuel oil: 3.512 m³1 Fresh water: 442 m³ |
|
Manager |
Phelippe Barko Management Inc. |
|
Previous manager |
Shoei Kisen Kaisha Ltd Ehimeken |
|
Registered owner |
Konlink Shipping Pte Ltd. |
|
Previous registered owner |
Los Halillos Shipping Co SA |
|
Latest data adjustment |
19 January 2019 |
