Westerschelde 16 August 2016 |
 |
 |
 |
||
| Westerschelde 30/06/15 | Westerschelde 30/06/15 | WS 30/06/15 | ||
|
Name |
FLINTERSPIRIT |
|
Type |
Multi-purpose cargo ship - Container ship |
|
IMO-number |
9229049 |
|
Call sign |
PFCF |
|
Flag |
The Netherlands |
|
Port of registry |
Groningen |
|
GT |
4.503 t |
|
DWT |
6.358 t |
|
NT |
2.462 t |
|
Number of 20ft containers |
390 |
|
Length |
111,75 m overall 105,38 m between perpendiculars |
|
Breadth |
14,95 m moulded |
|
Draught |
Max: 6,37 m |
|
Air draft |
40,85 m in ballast |
|
Freeboard |
1.742 mm |
|
Depth |
8,25 m moulded |
|
Speed |
14,2 knots |
|
Built |
2001 |
|
Launch date |
17/02/2001 |
|
Delivery date |
21/03/2001 |
|
Builder |
Ferus Smit Leer GmbH Leer Germany |
|
Yard number |
327 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Single hull - Double bottom (e.g. interrupted in way of machinery space) |
|
Watertight compartments |
6 |
|
Movable bulkheads |
2x Moveable each 2 parts |
|
Continuous decks |
1 |
|
Main engine |
1x Wärtsilä Type 8R32E - 4 stroke single acting 8 cylinder 320 x 350 mm combustion engine 3.280 kW / 4.456 hp at 750 rpm Built: 2000 Manufacturer: Wärtsilä NSD, Zwolle - The Netherlands |
|
Propellers |
1x Screw propeller controllable pitch - aft at 195 rpm |
|
Boilers |
1x CHO Gekakonus 1,00 m² - 10,0 bar 1x CHR Gekakonus 1,00 m² - 10,0 bar |
|
Electric installations |
1x Plant 400 V - 187.5 kVA 1x Plant 400 V - 187.5 kVA 1x Plant 400 V - 565 kVA 1x Plant 400 V - 106,3 kVA |
|
Shaft generator |
1x 430 kVA - 344 kW |
|
Generators |
2x Main diesel generatorsets each 187 kVA - 150 kW - 222 hp |
|
Emergency generator |
1x Diesel generatorset 106,3 kVA - 85 kW - 116 hp |
|
Compressed air receivers |
2x Receivers each 250 litres - 30,0 bar |
|
Bow thruster |
1x 350 kW |
|
Number of holds |
2 Hold 1: 27,30 x 12,65 x 9,44 m Hold 2: 53,70 x 12,65 x 9,44 m |
|
Cargo hold capacity |
Grain: 9.052 m³ Bale: 8.620 m³ |
|
Hold ventilation |
6x Air-changes/hour |
|
Number of hatches |
2 Hatch 1: 27,30 x 12,60 m Hatch 2: 53,70 x 12,60 m |
|
Max permitted loads |
Tanktop: 15,0 t/m² Hatchcovers: 1,75 t/m² |
|
Tank capacities |
IFO: 438,75 m³ MGO: 41 m³ Freshwater: 44,4 m³ Ballast water: 2.529,4 m³ |
|
Anchor equipment |
3x Anchors weight each 3.060 kg Chain length 495,00 m |
|
Manager |
Flinter Management B.V. Barendrecht The Netherlands |
|
Previous managers |
03/2001 - 2009 Flinter Groningen B.V., Groningen, Groningen - The Netherlands 2009 - 10/2013 Flinter Management B.V., Barendrecht - The Netherlands |
|
Owner |
Flinterspirit III B.V Groningen The Netherlands |
|
Previous owners |
03/2001 - 2009 C.V. Scheepvaartonderneming Flinterspirit, Groningen - The Netherlands 2009 - 10/2013 Flinterspirit B.V., Groningen - The Netherlands |
|
Renamed |
01/2017 Spirit The Netherlands, Groningen - Call Sign: PFCF Manager: Thorco Shipping A.S., Hellerup - Denmark Owner: Spirit II Shipping B.V., Groningen - The Netherlands 06/2021 Kaileen Malta, Valletta - Call sign: 9HA3252 Owner: HS Kaileen OU, Tallinn (Reval) - Estonia Manager: Hansa Shipping Ltd., Tallinn (Reval) - Estonia |
|
Latest data adjustment |
05 August 2023 |
