Westerschelde 28 February 2019 |
|
Name |
INCHEON BAY |
|
Type |
Bulk carrier - Handysize - Strengthened for heavy cargo loading |
|
IMO-number |
9791963 |
|
Call sign |
VRQO6 |
|
Flag |
Hong Kong - China |
|
Port of registry |
Hong Kong |
|
GT |
23.432 t registered |
|
DWT |
37.501 t |
|
NT |
12.197 t registered |
|
Length |
179,97 m overall |
|
Breadth |
29,80 m moulded |
|
Draught |
Summer: 10,54 m |
|
Moulded L x B x D |
173,00 x 29,80 x 15,00 m |
|
Registered L x B x D |
173,52 x 29,80 x 15,00 m |
|
Freeboard |
Summer: 4.500 mm |
|
Depth |
5,00 m moulded |
|
Speed |
Service: 14,7 knots Max: 16,1 knots |
|
Built |
2017 |
|
Keel laid |
36/11/2013 |
|
Launch date |
04/02/2017 |
|
Date of completion |
22/03/2017 |
|
Builder |
Shimanami Shipyard Co., Ltd. |
|
Yard number |
S-H647 |
|
Hull material |
Steel |
|
Hull type |
Double side |
|
Main engine |
1x MAN-B&W/Makita - 2 stroke single acting 6 cylinder 500 x 2.000 mm combustion engine 6.780 kW at 108,0 rpm Manufacturer: Makita Corporation |
|
Propeller shaft |
1x Oil lubrication shaft without monitoring device Diameter: 450 mm |
|
Propellers |
1 |
|
Boilers |
1x Auxiliary Vertical boiler - 8,0 bar Evaporation: 2,40 t/h Manufacturer: Miura Co., Ltd. |
|
Generators |
4x Generators total 2.015 kVA |
|
Cargo hold capacity |
Bale: 45.613,30 m³ Grain: 47.369,83 m³ |
|
Tank capacities |
Fuel oil: 1.945,85 m³ Fresh water: 294,84 m³ |
|
Cargo gear |
4x Cranes - SWL 30,5 t each |
|
Manager |
Pacific Basin Shipping Hong Kong Ltd. |
|
Registered owner |
Incheon Bay Ltd. |
|
Latest data adjustment |
27 March 2019 |
