Niklas 01

Svolvær, Norway 02 June 2019



Name

NIKLAS

Type

General dry cargo ship

IMO-number

9809241

Call sign

LDXZ

Flag

Norway

Port of registry

Tromsø

GT

282 t

DWT

446 t

NT

112 t

Length

26,25 m overall

23,95 m between perpendiculars

Breadth

11,60 m

Draught

Max: 2,00 m

Depth

4,35 m

Speed

12,4 knots

Built

2016

Builder

Fitjar Mekaniske Verksted AS
Fitjar
Norway

Yard number

218

Hull material

Steel

Main engine

Diesel/ Electric propulsion

2x Scania DI13 combustion engines each 502 bhp / 375 kW

Gearbox

1x Finnøy 2G27-42F

Propellers

1x Propeller diameter 1,9 m in nozzle

Generators

2x Diesel generatorsets each 515 kW

1x Diesel generatorset 55 kW

Bow thruster

2x Fixed propeller each 185 kW electric operation

Deck capacity

225 t

Hold capacity

150 m³

Deck equipment

1x Winch 80,0 tons, load measurement and length measurement. Capacity for 1.000 m rope

diameter 68 mm, radio control

1x Deck winch 30 tons, radio control mounted in common frame with 80 tons winch

1x Tire winch 10 tons

1x Roller diameter1.000 mm, length 2.000 mm

3x Capstan 3,0 ton

1x Towing hook - SWL 15 ton

Tank capacities

Ballast: 65 m³

Fresh water: 60 m³

Fuel oil: 60 m³

Cargo gear

1x Crane PK 150002MH 21,50 m range

1x Crane PK 50002MG 20,50 m range

Accommodation

4 People in 1-man cabins

2 People in 2 man cabins

Day room with galley and dining area

Manager

Finnsnes Dykk & Anleggservice AS
Trollvikveien 10
9307 Finnsnes
Norway

Registered owner

SG Finans AS
Strandveien 18
1366 Lysaker
Norway

Latest data adjustment

01 August 2019
