Westerschelde 22 August 2017 |
 |
|
| Westerschelde 13/07/18 | |
|
Name |
PACIFICA |
|
Previous names |
08/2009 - 11/2009 Ellensborg 11/2009 - 2016 Se Pacifica |
|
Type |
Multi-purpose dry carrier - Equipped for carriage of containers - Strengthened For Heavy Cargo |
|
IMO-number |
9431460 |
|
Call sign |
9V8831 |
|
Flag |
Republic of Singapore |
|
Port of registry |
Singapore City |
|
Previous flags |
2009 - 12/2010 Gibraltar |
|
GT |
9.627 t |
|
DWT |
Summer: 12.649 t |
|
Number of 20ft containers |
In hold: 334 On deck: 331 Total: 665 |
|
Number of 40ft containers |
In hold: 158 + 22 TEU On deck: 136 + 24 TEU Total: 294 + 46 TEU |
|
Container capacity 14t |
528 |
|
Reefer capacity |
50 |
|
Length |
138,50 m overall |
|
Breadth |
21,00 m moulded |
|
Draught |
Max: 8,01 m |
|
Moulded L x B x D |
130,71 x 21,00 x 11,00 m |
|
Freeboard |
3.018 mm |
|
Depth |
11,00 m moulded |
|
Speed |
Max: 15,0 knots Service: 13,5 knots |
|
Built |
2009 |
|
Keel laid |
01/12/2008 |
|
Launch date |
23/05/2009 |
|
Delivery date |
09/06/2009 |
|
Builder |
Taizhou Sanfu Ship Engineering Co., Ltd. Taizhou Jiangsu China |
|
Yard number |
SF060106 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Single hull double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
5 |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 6M32 - 4 stroke 6 cylinder 430 x 610 mm combustion engine 5.400 kW at 500 rpm Build: 28/04/2007 Manufacturer: Caterpillar Motoren GmbH & Co. KG, Rostock - Germany |
|
Propellers |
1x Controllable pitch propeller - aft at 132,0 rpm |
|
Boilers |
1x Boiler type thermal oil heater, exhaust gas heated - 10,0 bar Heating surface: 89,0 m² Year of manufacture: 28/04/2008 Manufacturer: Tube-Tec Rohrverformungstechnik GmbH boiler- Germany 1x Boiler type thermal oil heater, oil fired - 13,0 bar Heating surface: 39,0 m² Year of manufacture: 2008 Manufacturer: Alfa Laval Aalborg A/S |
|
Electric installations |
3x Plant 400 V each 532 kW 1x Plant 400 V - 700 kW 1x Plant 400 V - 110 kW 2x Plants each 24 V - 80 Ah 1x Plant 24 V - 85 Ah 1x Plant 24 V - 102 Ah 3x Plants each 24 V - 120 Ah |
|
Shaft generator |
1x 700 kW |
|
Generators |
3x Main diesel generators each 532 kW |
|
Emergency generator |
1x diesel generatorset 110 kW |
|
Batteries |
3x Batteries for diesel star, each 120 Ah 1x Battery for automation 102 Ah 1x Battery for automation 85 Ah 2x Batteries for diesel star, each 80 Ah |
|
Compressed air receivers |
2x Receivers each 1.000 litres - 30,0 bar 1x Receiver 60 litres - 30,0 bar 1x Receiver 1.000 litres - 10,0 bar 1x Receiver 250 litres - 10,0 bar |
|
Bow thruster |
1x Jamstram transverse thruster 500 kW |
|
Number of holds |
3 Hold 1: 18,75 x 15,0 2/10,02 x 10,53 m Hold 2: 42,00 x 17,50 x 11,18 m Hold 3: 25,50 x 17,48 x 10,77 m |
|
Cargo hold capacity |
Hold 1: 2.663,80 m³ Hold 2: 7.957,50 m³ Hold 3: 4.822,70 m³ Bale: 14.856 m³ Grain: 15.952 m³ |
|
Number of hatches |
3 Hatch 1: 18,75 x 15,00 / 10,00 m Hatch 2: 42,00 x 17,50 m Hatch 3: 25,50 x 17,50 m |
|
Hatch type |
Steel folding hatch covers |
|
Tank capacities |
Heavy fuel oil: 948 m³ Gas oil: 150 m³ Lub oil: 54 m³ Frisch water: 141 m³ Ballast water: 5.000 m³ |
|
Anchor equipment |
3x Anchors weight each 4.590 kg Chain length: 550,00 m |
|
Cargo gear |
2x NMF cranes (portside) each 150,00 / 120,00 / 70,00 t |
|
Crew size |
20 |
|
ISM & commercial manager |
Skeiron Logistics Pte Ltd. Republic of Singapore |
|
Registered owner |
Saphir Shipping Pte Ltd. |
|
Latest data adjustment |
15 June 2024 |
