Name |
JADE I |
|
Previous names |
1998 - 07/2004 Glory Challenger 07/2004 - 10/2013 Global Challenger |
|
Type |
Bulk carrier |
|
IMO-number |
9162411 |
|
Call sign |
3FZW |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
Previous flags |
1998 - 2013 Republic of Singapore, Singapore City |
|
GT |
15.660 t registered |
|
DWT |
Summer: 25.012 t |
|
NT |
8.745 t registered |
|
Length |
159,92 m overall |
|
Breadth |
26,00 m |
|
Draught |
Summer: 9,80 m |
|
Moulded L x B x D |
149,80 x 26,00 x 13,50 m |
|
Registered L x B x D |
150,75 x 26,00 x 13,50 m |
|
Freeboard |
Summer: 3.745 mm |
|
Depth |
13,50 m moulded |
|
Speed |
Service: 14,5 knots Max: 16,8 knots |
|
Built |
1998 |
|
Keel laid |
24/12/1997 |
|
Launch date |
09/06/1998 |
|
Date of completion |
27/07/1998 |
|
Builder |
Imabari Shipbuilding Co., Ltd. Imabari Japan |
|
Yard number |
536 |
|
Hull material |
Steel |
|
Main engine |
1x Mitsui/MAN-B&W - 2 stroke single acting 6 cylinder 420 x 1.764 mm combustion engine 6.156 kW / 8.369 hp at 136,0 rpm Manufacturer: Mitsui Engineering & Shipbuilding Co., Ltd. Tamano Works - Japan |
|
Propeller shaft |
1x Oil lubrication shaft without monitoring device Diameter: 420 mm |
|
Propellers |
1 |
|
Boilers |
1x Auxiliary vertical boiler - 7,9 bar Evaporation: 1,95 t/h Manufacturer: Miura Co., Ltd. |
|
Generators |
3x Generators total 1.060 kW |
|
Cargo hold capacity |
Bale: 30.892 m³ Grain: 31.961 m³ |
|
Tank capacities |
Fuel oil: 1.954 m³ Fresh water: 440 m³ |
|
Cargo gear |
3x Deck cranes - SWL 30,0 t each |
|
Manager |
Sunberry Oceanways Ltd. Granikou Street Marousi, 151 25 Athens Greece |
|
Registered owner |
Koumasi Shipping Ltd. Liberia Monrovia |
|
Previous names & owners |
1998 - 07/2004 Glory Challenger - Glory Challenger Sg Corporation 07/2004 - 10/2013 Global Challenger - Ocean Chain Pte Ltd. |
|
Latest data adjustment |
04 September 2019 |
