Westerschelde 21 June 2018 |
 |
 |
 |
 |
|||
| Westerschelde 23/12/19 | Westerschelde 23/12/19 | Westerschelde 09/11/19 | Westerschelde 22/05/16 | |||
|
Name |
PETALON |
|
Hellenic name |
ΠΕΤΑΛΟΝ |
|
Type |
Bulk carrier |
|
IMO-number |
9469041 |
|
Call sign |
9HA2224 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
Previous names |
2010 -2020 Greece, Andros - Call sign: SVAZ8 |
|
GT |
47.984 t Suez: 49.716,64 t |
|
DWT |
Summer: 87.328 t |
|
NT |
27.675 t Suez: 45.043,48 t |
|
Light displacement |
14.765 t |
|
Length |
229,00 m overall 221,00 m between perpendiculars |
|
Breadth |
36,84 m extreme |
|
Draught |
13,5 knots laden 14,5 knots ballast |
|
Keel to mast end |
44,00 m |
|
Depth |
19,90 m moulded |
|
Speed |
13,8 knots |
|
Build |
2010 |
|
Keel laid |
23/11/2009 |
|
Date of completion |
15/04/2010 |
|
Builder |
Hudong Zhonghua Shipbuilding Group Shanghai China |
|
Yard number |
H1570A |
|
Hull material |
Steel - Part higher tensile steel |
|
Hull type |
Double skinned |
|
Watertight bulkheads |
13 |
|
Watertight compartments |
10 |
|
Continuous decks |
1 |
|
Main engine |
1x Hudong/Wärtsilä 6RTA58T-B - 2 stroke 6 cylinder 580 x 2.416 mm combustion engine 10.500 kW / 14.266 hp at 95,0 rpm Builder Hudong Heavy Machinery Co., Ltd |
|
Propellers |
1x Fixed pitch propeller - aft at 95,0 rpm |
|
Boilers |
1x CHO Aalborg 12,19 m² - 7,0 bar 1x CHR Aalborg 34,00 m² - 9,0 bar |
|
Generators |
3x Daihatsu 5DK-20 - 4 stroke 5 cylinder 200 x 300 mm diesel egirine 600 kW / 897 hp connected with generators each 750 kVA |
|
Emergency generator |
1x MAN D0824LE 4 stroke 4 cylinder diesel 99 kW / 149 hp connected with generator 124 kVA |
|
Number of holds |
7 |
|
Cargo hold capacity |
Hold 1: 10.950,60 m³ Hold 2: 16.112,20 m³ Hold 3: 14.658,10 m³ Hold 4: 14.681,90 m³ Hold 5: 14.730.60 m³ Hold 6: 16.143.10 m³ Hold 7: 12.820.90 m³ Total: 100.097,30 m³ (Grain) |
|
Number of hatches |
7 Hatch 1: 13,76 x 14,00 m Hatches 2-7: 15,48 x 17,00 m |
|
Hatch cover type |
MacGregor side rolling |
|
Max permitted loads |
Tanktop: Hold 1: 30,42 t/m² Hold 2: 18,93 t/m² Hold 3: 30,41 t/m² Hold 4: 18,96 t/m² Hold 5: 30,41 t/m² Hold 6: 18,92 t/m² Hold 7: 30,55 t/m² |
|
Tank capacities |
Cargo ballast:14.681,9 m³ Diesel oil: 183,8 m³ Freshwater: 606,7 m³ Fuel oil: 3.064,8 m³ Lube oil: 166,6 m³ |
|
Cargo gear |
Gearless |
|
Crew |
20 |
|
Crew size |
30 |
|
ISM & commercial manager |
Goulandris Brothers Hellas Ltd. 85 Akti Miaouli 18538 Piraeus Greece |
|
Registered owner |
Ice Bird Shipping SA - Republic of Panama c/o Goulandris Brothers (Hellas) Ltd. Hella, 85, Akti Miaouli 185 38 Piraeus Greece |
|
Latest data adjustment |
09 October 2024 |
