Westerschelde 06 November 2018 |
|
Name |
DANICA HAV |
|
Previous names |
1984 - 1994 Birka 1994 - 09/2001 Union Arbo |
|
Type |
General cargo ship - Equipped for carriage of containers - Strengthened for heavy cargo |
|
IMO-number |
8401535 |
|
Call sign |
C6ML9 |
|
Flag |
Bahamas |
|
Port of registry |
Nassau |
|
GT |
1.536 t |
|
DWT |
2.310 t |
|
DWCC |
Summer: 2.150 t Winter: 2.080 t |
|
NT |
774 t |
|
Number of 20ft containers |
In hold: 48 on deck: 32 Total: 80 |
|
Length |
82,45 m overall 76,80 m between perpendiculars |
|
Breadth |
11,30 m extreme |
|
Draught |
Max: 4,18 m |
|
Keel to top with antenna |
20,10 m |
|
Air draft |
17,50 m in ballast |
|
Depth |
5,40 m moulded |
|
Speed |
10,0 knots |
|
Built |
1984 |
|
Keel laid |
07/03/1984 |
|
Launch date |
07/04/1984 |
|
Date of completion |
01/05/1984 |
|
Builder |
Schiffswerft Hugo Peters Wewelsfleth Peters & Co. GmbH |
|
Yard number |
599 |
|
Hull material |
Steel |
|
Movable bulkheads |
5 |
|
Main engine |
1x Kloeckner-Humboldt-Deutz BA8M528 - 8 cylinder combustion engine 700 kW |
|
Propellers |
1x Fixed propeller |
|
Generators |
1x Scania DN801 A 20 T main diesel generatorset 95 hp - 78 kVA 1x Scania DSI1145 A 21 T main diesel generatorset 254 hp - 210 kVA |
|
Emergency generator |
1x Diesel generatorset 45 kW |
|
Bow thruster |
1x Jastram 132 kW / 179 hp |
|
Number of holds |
1 49,80 x 9,00 x 6,30 m |
|
Cargo hold capacity |
Bale & grain: 2.865 m³ / 101.196 ft³ |
|
Timber capacity |
2.700 m³ |
|
Number of hatches |
1 49,80 x 9,00 m |
|
Hatch type |
Piggy back multi stack |
|
Hold ventilation |
6x Air-changes/hours |
|
Max permitted loads |
Hatch cover: 1,5 t/m² Tanktop: 11,0 t/m² |
|
Tank capacities |
Water ballast: 967,6 m³ Gas oil: 111,6 m³ Fresh water: 59,4 m³ |
|
Anchor equipment |
Length: 385,00 m Diameter: 30 mm |
|
Crew size |
6 |
|
Manager |
HAV Ship Management NorRus AS |
|
Registered owner |
Hav Bulk AS |
|
Previous names & shipping companies |
1984 - 1994 Birka - H.Beutler 1994 - 09/2001 Union Arbo - Union Tpt Group |
|
Latest data adjustment |
05 November 2019 |
