Westerschelde 31 January 2020 |
 |
 |
 |
||
| Westerschelde 31/01/20 | Westerschelde 06/04/19 | Doel, Belgium 29/07/19 |
|
Name |
STAR KIRKENES |
|
Type |
Multi-purpose carrier - Solid bulk cargo carriage - Container carriage |
|
Main products |
Baled pulp, ore, grain, cement, paper, packaged lumber and other solid bulk cargoes |
|
IMO-number |
9396127 |
|
Call sign |
LAHR7 |
|
Flag |
Norway |
|
Port of registry |
Bergen |
|
GT |
37.158 t |
|
DWT |
Summer: 49.924 t |
|
NT |
13.824 t |
|
Number of 20ft containers |
On hatch cover: 802 In hold: 618 Total: 1.420 |
|
Length |
208,73 m overall 197,40 m between perpendiculars |
|
Breadth |
32,25 m extreme |
|
Draught |
Max: 12,34 m |
|
Air draft |
Max: 47,60 m |
|
Depth |
19,50 m to main deck |
|
Speed |
Max: 16,0 knots |
|
Built |
2009 |
|
Keel laid |
23/01/2009 |
|
Launch date |
30/03/2009 |
|
Date of completion |
25/06/2009 |
|
Builder |
Hyundai Mipo Dockyard Co., Ltd. South Korea |
|
Yard number |
8001 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Continuous decks |
1 |
|
Main engine |
1x Hyundai/MAN-B&W 5S60MC-C Mk 8 - 2 stroke single acting 5 cylinder 600 x 2.400 mm combustion engine: MCR: 11.900 kW at 105,0 rpm NCR: 10.710 kW at 101,4 rpm |
|
Propellers |
1x Fixed pitch mono-block propeller |
|
Boilers |
1x Auxiliary boiler, exhaust gas heated (Economizer) 1x Auxiliary boiler, oil/gas fired Manufacturer: Kangrim |
|
Generators |
2x Hyundai 7H21/32 - 4 stroke single acting 7 cylinder diesel engine each 1.440 kW at 900 rpm connected with generators each 1.250 ekW 1x Hyundai 5H21/32 4 stroke single acting 5 cylinder diesel engine 800 kW connected with generator 750 ekW Manufacturer: Hyundai Heavy Industries Co., Ltd. |
|
Emergency generator |
1x Cummins N855-M/ - D(M) diesel generatorset |
|
Compressed air receivers |
2x Sauer WP200 main compressor-unit - 30,0 bar 1x Sauer WP33L emergency compressor: compressor - 30,0bar 1x Atlas Copco Type GA 37 VSD-175-60 compressor |
|
Thrusters |
1x Bow thruster Rolls Royce type TT 2000, Output 1.500 KW 1x Stern thruster Rolls Royce type TT 1000, Output 750 KW |
|
Number of cargo holds |
11 Box-shaped cargo holds |
|
Cargo hold capacity |
Bale: Hold 1: 4.435 m³ Hold 2: 6.545 m³ Hold 3: 6.713 m³ Hold 4: 6.713 m³ Hold 5: 6.713 m³ Hold 6: 6.713 m³ Hold 7: 6.713 m³ Hold 8: 6.713 m³ Hold 9: 6.545 m³ Hold 10: 5.553 m³ Hold 11: 1.849 m³ Total: 65.206 m³ |
|
Number of hatches |
11 |
|
Tank capacities |
Ballast: 20.668,6 m³ |
|
Anchor equipment |
Length: 660,00 m Diameter: 78 mm |
|
Lifting equipment |
2x Provision cranes - SWL 4,0 t |
|
Cargo gear |
2x Gantry cranes on deck - SWL 70,0 t |
|
Crew size |
32 |
|
Manager |
Grieg Star AS C Sundtsgate 17/19 5004 Bergen Norway |
|
Owner |
Grieg International II Care of G2 Ocean AS C Sundts gate 17 5004 Bergen Norway |
|
Registered owner |
Mi-Das Line S.A. Vallarino Building, 3rd Floor 52nd And Elvira Mendez Street Panama City Republic of Panama |
|
Latest data adjustment |
26 April 2021 |
