Westerschelde 02 July 2019 |
 |
| Antwerpen 01/07/19 |
|
Name |
RIX SPRING |
|
Previous names |
1996 - 12/1998 RMS Algol 12/1998 - 01/2006 Algol 01/2006 - 2015 Coimbra 2018 - 2018 Celtic Vigour |
|
Type |
Sea & river going general cargo ship - Equipped for carriage of containers |
|
IMO-number |
9137296 |
|
Call sign |
D5RX4 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
Previous flags |
Cyprus, Limassol - Call sign: C4HU2 2013 - 2018 Antigua & Barbuda, St. John’s - Call sign: V2GF2 |
|
GT |
1.864 t |
|
DWT |
2.489 t |
|
DWCC |
Summer: 2.350 t Winter: 2.250 t |
|
NT |
938 t |
|
Displacement |
3.650 t |
|
Lightship |
1.137,5 t |
|
Number of 20ft containers |
105 |
|
Length |
82,38 m overall 79,82 m registered |
|
Breadth |
11,35 m registered |
|
Draught |
Summer: 4,80 m Winter: 4,69 m |
|
Air draft |
Ballast: 31,45 m |
|
Forecastle |
6,62 m |
|
Poop |
15,60 m |
|
Freeboard |
Summer: 1.311 m Winter: 1.411 mm |
|
Depth |
6,10 m |
|
Speed |
Ballast: 10,0 knots Loaded: 9,5 knots |
|
Built |
1996 |
|
Keel laid |
10/04/1995 |
|
Launch date |
15/11/1995 |
|
Date of completion |
04/01/1996 |
|
Builder |
Slovenske Lodenice A.S. Rolnickej Skoly 1519 945 25 Komarno Slovak Republic |
|
Yard number |
1502 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Double hull Partly double bottom |
|
Watertight bulkheads |
4 |
|
Movable bulkheads |
2 |
|
Continuous decks |
2 |
|
Main engine |
1x Deutz MWM SBV 8 M 628 - 4 stroke 8 cylinder single acting 240 x 280 mm combustion engine 1.350 kW at 800 rpm Year of Manufacture: 1995 Manufacturer: Deutz MWM Motoren-Werke Mannheim AG,Mannheim - Federal Republic of Germany |
|
Gearbox |
1x Reintjes WAF-1941 |
|
Propellers |
1x Solid pitch propeller - aft at 256 rpm |
|
Electric installations |
2x Plants each 380/220 V - 85 kVA 1x Plant 380 V - 85 kVA |
|
Generators |
2x Deutz TD226-6 main diesel generatorsets each 85 kVA |
|
Emergency generator |
1x Deutz TD226-6 diesel generatorset 85 kVA |
|
Compressed air receivers |
2x Receivers each 125 litres - 30,0 bar 1x Receiver 10 litres - 30,0 bar |
|
Bow thruster |
1x Omega jet 3100-4K - 261 kW, forward |
|
Number of holds |
1x Box 53,40 x 9,00 x 7,59 m |
|
Cargo hold capacity |
Grain: 3.485 m³ |
|
Number of hatches |
1 53,40 x 9,00 m |
|
Hatches type |
Hydraulic folding |
|
Max permitted loads |
Hatch cover: 1,30 t/m² Tanktop: 12,0 t/m² |
|
Tank capacities |
Fuel oil: 172 m³ Fresh water: 22,0 m³ Ballast water: 1.059 m³ |
|
Anchor equipment |
3x Anchors weight each 1.290 kg Chain length: 385,00 m |
|
Crew size |
10 |
|
Manager |
Baltic Shipping Company A/S Ved isefjorden 24 3390 hundested Denmark |
|
Previous names & owners |
1995 - 1995 RMS Algol - Elbe Trans Schiffahrts GmbH & Co KG 1995 - 2006 Algol - Elbe Trans Schiffahrts GmbH & Co KG 2006 - 2015 Coimbra - Salim Sg Co Ltd. 2018 - 2018 Celtic Vigour |
|
Special annotation |
Wheelhouse hydraulic lowering |
|
Latest data adjustment |
12 January 2020 |
