Westerschelde 06 July 2016 |
 |
|
| Westerschelde 15/02/16 | |
|
Name |
FRAKT VIK |
|
Previous names |
05/2010 - 02/2016 Jetstream |
|
Type |
Multi-purpose dry cargo carrier - Single Deck |
|
IMO-number |
9356579 |
|
Call sign |
5BKU4 |
|
Flag |
Cyprus |
|
Port of registry |
Limassol |
|
Previous flags |
05/2010 - 02/2016 The Netherlands, Rotterdam - Call sign: PBYR |
|
GT |
2.999 t |
|
DWT |
Summer: 4.500 t |
|
NT |
1.669 t |
|
Number of 20ft containers |
106 |
|
Length |
89,95 m overall 84,98 m between perpendiculars |
|
Breadth |
14,40 m |
|
Draught |
Full laden: Summer: 6,30 m Winter: 6,17 m |
|
Air draft |
29,00 m Mast down: 13,00m |
|
Depth |
7,35 m |
|
Speed |
12,0 knots |
|
Built |
2010 |
|
Keel laid |
03/12/2007 |
|
Launch date |
03/12/2007 |
|
Delivery date |
21/05/2010 |
|
Builder casco |
Dongfeng Shipbuilding Hangzhou China |
|
Builder completion |
Bijlsma Shipyard B.V. (Veka) Lemmer The Netherlands |
|
Yard number |
757 |
|
Hull material |
Steel |
|
Movable bulkheads |
2x May be placed in 6 positions for cargo separation |
|
Continuous decks |
1 |
|
Main Engine |
1x Wärtsilä 6L26A2 - 4 Stroke single acting 6 cylinder 240 X 360 mm combustion engine 1.860 kW / 2.527 bhp at 900 rpm Manufacturer: Wärtsilä Diesel, Trieste - Italy |
|
Propellers |
1x KaMeWa controllable pitch propeller |
|
Boilers |
1x Auxiliary boiler, exhaust gas heated 1x Auxiliary boiler, oil/gas fired |
|
Shaft generator |
1x HCM543C 2C generator 32 kW |
|
Generators |
2x Scania D9 main diesel generatorsets each 271 kW Builder: Scania CV AB, Industrial & Marine Engines |
|
Bow thruster |
250 kW |
|
Number of holds |
1 63,00 x 11,70 x 8,40 m |
|
Cargo hold capacity |
6.046 m³ / 214.000 ft³ |
|
Hatches |
10 pcs 6,35 x 12,03 m |
|
Hatches type |
Hatches pontoon system |
|
Max permitted loads |
On hatches: 1,6 t/m² Tanktop: 15,0 t/m² |
|
Tank capacities |
Ballast: 1.689 m³ |
|
Cargo gear |
Gearless |
|
Manager |
Sætre & Sønner A.S. Mastrevik Norway |
|
Previous managers |
05/2010 - 02/2016 Q Shipping B.V., Ridderkerk - The Netherlands |
|
Registered owner |
Austrheim Frakt Mastrevik Norway |
|
Previous names & owners |
05/2010 - 02/2016 Jetstream - C.V. Scheepvaartonderneming 'Jetstream', Rotterdam - The Netherlands |
|
Latest data adjustment |
14 February 2020 |
