Westerschelde 18 March 2018 |
 |
| Westerschelde 18/03/18 |
|
Name |
JAG AMAR |
|
Type |
Bulk carrier - Carriage of dangerous goods - Kamsarmax |
|
IMO-number |
9723851 |
|
Call sign |
AWLE |
|
Flag |
India |
|
Port of registry |
Mumbai |
|
GT |
44.127 t |
|
DWT |
Summer: 82.084 t |
|
NT |
27.581 t |
|
Length |
229,00 m overall 225,30 m between perpendiculars |
|
Breadth |
32,26 m moulded |
|
Draught |
Max: 14,47 m |
|
Depth |
20,00 m moulded |
|
Speed |
Max: 14,5 knots |
|
Built |
2017 |
|
Keel laid |
26/06/2014 |
|
Delivery date |
11/01/2017 |
|
Builder |
Jiangsu New Yangzi Shipbuilding Co., Ltd. Jingjiang Park Of Jiangyin Economic Development Zone Of Jiangsu Province, 214532 China |
|
Yard number |
YZJ2013-1111 |
|
Hull material |
Steel |
|
Main engine |
1x MAN-B&W/Hudong Heavy Machinery 6S60ME-C8.2 - 2 stroke 6 cylinder 600 x 2.400 mm combustion engine 9.801 kW at 90,3 rpm Manufacturer: Hudong Heavy Machinery Co., Ltd. |
|
Propellers |
1x Fixed pitch propeller Manufacturer: Changzhou Zhonghai Marine Propeller Co., Ltd. |
|
Boilers |
Fire exhaust gas composite boiler - 9,0 bar Manufacturer: Zhangjiagang Greens Shazhou Boiler Co., Ltd. |
|
Generators |
3x Daihatsu 6DE-18 - 6 cylinder 185 x 280 mm diesel engines each 690 kW at 900 rpm coupled with generators each 630 kW Manufacturer: Daihatsu Diesel Mfg. Co. Ltd. / HHI Electro Electric System |
|
Cargo hold capacity |
97.738,4 m³ |
|
Tank capacities |
Fresh water: 534,50 m³ Fuel oil: 2.664,3 m³ Lub oil: 208,10 m³ Ballast: 35.486,90 m³ |
|
Lifting equipment |
1x Engine room crane - SWL 4,0 t Manufacturer: Jiangyin Chengjiang Ships Equipment Co., Ltd. 1x Provision crane - SWL 4,0 t Manufacturer: Shanghai Heng Yuan Marine Equipment Co. Ltd. 1x Suez canal boat crane - SWL 4,0 t Manufacturer: Taizhou Kaixin Shipping Machine Co., Ltd. |
|
Cargo gear |
Gearless |
|
Crew |
26 |
|
Manager |
Great Eastern Shipping Company Ltd. |
|
Registered owner |
Great Eastern Shipping Company Ltd. Ocean House, 134/A, B Wing, BDD Chawls Worli, Worli Mumbai, Maharashtra 400018 India |
|
Latest data adjustment |
20 March 2020 |
