Name |
MARTEN |
|
Previous names |
2012 - 10/2013 Marten 10/2003 - 2015 Wilson Lisbon |
|
Type |
Multi-purpose dry cargo ship - Equipped for carriage of containers - Strengthened for heavy cargo - Gearless single decker |
|
IMO-number |
9617337 |
|
Call sign |
5BNU3 |
|
Flag |
Cyprus |
|
Port of registry |
Limassol |
|
GT |
2.589 t |
|
DWT |
Summer: 3.785 t Winter: 3.660 t |
|
DWCC |
Summer: 3.600 t Winter: 3.500 t |
|
NT |
1.386 t |
|
Number of 20ft containers |
36 |
|
Length |
89,92 m overall 83,95 m between perpendiculars |
|
Breadth |
12,90 m extreme 12,80 m moulded |
|
Draught |
Summer: 5,55 m Winter: 5,43 m |
|
Air draft |
15,85 m |
|
Depth |
7,10 m moulded to main deck |
|
Speed |
Service: 11,0 knots |
|
Built |
2012 |
|
Keel laid |
19/12/2008 |
|
Launch date |
01/03/2012 |
|
Date of completion |
17/05/2012 |
|
Builder |
Slovenské Lodenice Komárno a.s. Komárno Slovakia |
|
Yard number |
3804 |
|
Hull material |
Steel |
|
Watertight bulkheads |
4 |
|
Movable bulkheads |
3x Moveable grain bulkheads with 10 stowage positions |
|
Continuous decks |
1 |
|
Main engine |
1x Caterpillar/MaK 8M20C - 4 stroke single acting 8 cylinder200 x 300 mm combustion engine 1.520 kW at 1.000 rpm Build: 2011 |
|
Gearbox |
1x Jake PWV-500-250 - reduction1:4.081 |
|
Propellers |
1x Controllable pitch propeller - aft at 245 rpm Diameter: 3.150 mm |
|
Electric installations |
400/230 Volt - 50 Hz |
|
Shaft generator |
1x Dessau AEM SE-400-SA4 - 650 kVA |
|
Generators |
2x Volvo D9MG HE/KC - 6 cylinder 120 x 138 mm main diesel engine each 239 kW at 1.500 rpm coupled with Stamford HCM434D each 230 kVA Build: 2011 |
|
Emergency generator |
1x Volvo Penta D7AT - 6 cylinder 108 x 130 mm diesel engine 122 kW at 1.500 kW coupled with Stamford UCM374F 130 kVA Build: 201 |
|
Compressed air receivers |
2x Starting air compressors each 125 litres - 30,0 bar |
|
Bow thruster |
1x Fixed pitch propeller type STT110LK - Output 185 kW at 790 rpm |
|
Cargo hold |
1x Boxshaped cargo hold 57,85 x 10,20 x 8,15 m |
|
Cargo hold capacity |
Grain: 4.636 m³ / 167.173 ft³ Bale: 4.636 m³ / 167.173 ft³ |
|
Hold ventilation |
6 per hour |
|
Number of hatches |
1 57,85 x 10,20 m |
|
Hatch type |
Folding type |
|
Max permitted loads |
Tanktop: 15,0 t/m² Hatches: 1,56 t/m² |
|
Tank capacities |
Ballast approx: 1.457,00 m³ HFO approx: 193,50 m³ MGO approx: 91,10 m³ Potable water: 52,00 m³ Lubrication oil: 13,90 m³ Dirty oil: 6,4 m³ Sewage: 6,4 m³ Bilge water: 2,4 m³ Sludge: 11,3 m³ |
|
Anchor equipment |
3x Anchors weight 2.280 kg Length: 467,50 m Diameter: 36 mm |
|
Accommodation |
For Captain and Crew of a total 9 persons with heating, ventilation and air-conditioning |
|
Commercial manager |
Hermann Lohmann Bereederungen GmbH & Co. KG Boschstraße 15 49733 Haren (Ems) Germany |
|
ISM manager |
Hermann Lohmann Schiffahrtsverwaltungs GmbH |
|
Registered owner |
Hermann Lohmann Schiffahrts GmbH & Co. KG MS "MARTEN" |
|
Latest data adjustment |
24 March 2020 |
