Westerschelde 20 January 2020 |
 |
| Westerschelde 10/01/20 |
|
Name |
SOCRATIS |
|
Previous names |
2010 - 10/2012 Thalassini Kyra |
|
Type |
Bulk carrier |
|
IMO-number |
9452517 |
|
Call sign |
V7ZK2 |
|
Flag |
Marshall Islands |
|
Port of registry |
Majuro |
|
Previous flags |
2010 - 2012 Malta, Valletta - Call sign: 9HA2365 |
|
GT |
34.374 t Suez: 35.675,3 t |
|
DWT |
Summer: 58.609,2 t |
|
NT |
19.565 t Suez: 31.147,75 t Panama: 28.476 t |
|
Displacement |
69.919,8 t |
|
Length |
196,00 m overall 189,00 m between perpendiculars |
|
Breadth |
32,26 m moulded |
|
Draught |
Max: 13,03 m |
|
Freeboard |
5.621 mm |
|
Depth |
18,60 m moulded |
|
Speed |
14,0 knots |
|
Built |
2010 |
|
Keel laid |
02/03/2010 |
|
Launch date |
12/04/2010 |
|
Delivery date |
07/06/2010 |
|
Builder |
SPP Plant & Shipbuilding Co., Ltd. 1988, Chojeon-Ri Sanam-Myeon Sacheon South Korea |
|
Yard number |
H1032 |
|
Hull material |
Steel |
|
Main engine |
1x Doosan-MAN B&W 6S50MC-C - 2 stroke 6 cylinder 500 x 2.000 mm combustion engine 9.960 kW at 127,0 rpm Manufacturer: Doosan Engine Co. |
|
Propellers |
1x Fixed propeller |
|
Boilers |
1x Composite Auxiliary Boiler - 9,0 bar Manufacturer: SPP Machine Tech |
|
Generators |
1x Yanmar 6N21L-UV - 6 cylinder 210 x 290 mm combustion engines each 660 kW at 720 rpm connected to generators FE547B-10 each 600 kW Manufacturer: Yanmar Co., Ltd. / Taiyo Electric Co., Ltd. |
|
Number of cargo holds |
5 |
|
Cargo hold capacity |
75.530,50 m³ |
|
Number of hatches |
5 |
|
Tank capacities |
Ballast: 31.633,80 m³ Fuel oil: 2.215,80 m³ Fresh water: 303,20 m³ Lube oil: 129,70 m³ Diesel oil: 145,80 m³ |
|
Anchor equipment |
19 |
|
Lifting equipment |
1x Electric provision crane - SWL 3,0 t 1x Engine room crane - SWL 2,0 t Manufacturer: SPP Machine Tech |
|
Cargo gear |
4x MacGregor deck cranes - SWL 36,0 t Manufacturer: SPP Machine Tech |
|
Manager |
Navina Maritime SA 42, Vouliagmenis Avenue Voula, 166 73 Athens Greece |
|
Registered owner |
Myrtos Shipping SA c/o Navina Maritime SA 42, Vouliagmenis Avenue Voula, 166 73 Athens Greece |
|
Previous names & owners |
2010 - 10/2012 Thalassini Kyra - Acacia Development SA - Malta |
|
Latest data adjustment |
02 April 2020 |
