Antwerpen 07 October 2014 |
 |
 |
 |
 |
 |
||||
| Antwerpen 07/10/14 | Antwerpen 07/10/14 | Antwerpen 07/10/14 | Antwerpen 26/04/09 | Bergen, Norway 20/09/17 |
|
Name |
FRAM |
|
Previous names |
2007 Launch as: Polar Explorer |
|
Type |
Passengers vessel - Cruise ship |
|
IMO-number |
9370018 |
|
Call sign |
LADA7 |
|
Flag |
Norway |
|
Port of registry |
Tromsø |
|
GT |
11.647 t registered |
|
DWT |
984 t |
|
NT |
3.818 t |
|
Length |
113,65 m overall 99,22 m between perpendiculars |
|
Breadth |
20,20 m 26,90 m extreme |
|
Draught |
5,10 m |
|
Depth |
16,00 m |
|
Speed |
Service: 13,0 knots Max.: 16,6 knots |
|
Built |
2007 |
|
Keel laid |
21.08.2006 |
|
Date of completion |
23.04.2007 |
|
Builder |
Fincantieri Cantieri Navali Italiani S.p.A. Trieste |
|
Yard number |
6144 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Main engine |
4x MAK 6 M25 N4 diesel engines - each 1/980 kW total 7.924 kW / 10.774 hp |
|
Propeller |
2x Propellers with adjustable propellers blades |
|
Boilers |
4x Auxiliary boiler, exhaust gas heated 1x Auxiliary boiler, oil/gas fired |
|
Generators |
4x Caterpillar 6M25 diesel generatorsets Builder: Caterpillar Motoren GmbH & Co. KG |
|
Emergency generator |
Mitsubishi S12A2-M(P)TA diesel generatorset Builder: Mitsubishi Turbocharger and Engine Europe B.V. |
|
Bow thruster |
2 |
|
Ballast capacity |
795,1 m³ |
|
Passengers decks |
8 |
|
Cargo deck |
1 |
|
Passengers |
318 |
|
Number of beds |
276 |
|
Number of cars |
25 |
|
Manager |
Hurtigruten Group |
|
Registered owner |
Hurtigruten ASA |
