Malaga, Spain 18 March 2016 |
 |
 |
 |
 |
 |
 |
|||||
| Malaga, Spain 18/03/16 | Zeebrugge 28/04/14 | Zeebrugge 28/04/14 | Zeebrugge 28/04/14 | Malaga, Spain 01/03/17 | Zeebrugge 26/09/18 | |||||
|
Name |
MSC MAGNIFICA |
|
Type |
Passengers vessel - Cruise ship |
|
IMO-number |
9387085 |
|
Call sign |
3FLO4 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
95.128 t |
|
DWT |
Summer: 9.429 t t |
|
NT |
63.861 t |
|
Length |
293,80 m overall 269,14 m between perpendiculars |
|
Breadth |
32,30 m |
|
Draught |
Summer: 7,85 m |
|
Air draft |
59,64 m |
|
Freeboard |
2.779 mm |
|
Depth |
13,50 m |
|
Speed |
Max.: 23,0 knots Service: 22,0 knots |
|
Built |
2010 Refit: 2014 |
|
Keel laid |
05.10.2007 |
|
Launch date |
01.2009 |
|
Date of completion |
25.02.2010 |
|
Builder |
STX France Nantes |
|
Yard number |
T32 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Continuous decks |
17 |
|
Main engine |
Diesel/electric: 5x Diesel engines make Wärtsilä type 16V38B - each 11.600 kW total power 58.000 kW |
|
Electrical propulsion engine |
2x Converteam electric motors power each 17,5 MW total 35.000 kW / 47.554 hp Builder: Aceo leroy Somer |
|
Propelling type |
Electrical |
|
Propelling system |
2x Fixed propellers with conventional shafts |
|
Boilers |
1x CHR 7386 251,00 m² - 10,0 bar |
|
Generators |
5x Generators - 14.500 kVA - 11.600 kW - 15.761 hp |
|
Passengers decks |
12 |
|
Passengers |
3.223 |
|
Number of cabins |
1.257 |
|
Tank capacities |
Fuel oil: 3.901 m³ |
|
Crew |
941 |
|
Manager |
Mediterranean Shipping Geneva |
|
Owner |
MSC Crociere - Subsidiary of the Swiss MSC-Container Lines |
|
Registered owner |
Mediterranean Shipping Company S.A. (MSC) |
|
Latest data adjustment |
23 April 2016 |
