Westerschelde 25 October 2018 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 25/10/18 | WS 25/10/18 | Westerschelde 22/11/20 | Westerschelde 14/11/18 | Westerschelde 23/06/15 | Westerschelde 11/08/20 | |||||
|
Name |
WISBY VERITY |
|
Type |
Oil product tanker |
|
IMO-number |
9283459 |
|
Call sign |
PFFO |
|
Flag |
The Netherlands |
|
Port of registry |
Delfzijl |
|
Previous flags |
2004 - 2013 Sweden, Visby - Call sign: SBJH 2013 - 2016 The Netherlands, Zuidlaren - Call sign: PCTJ 2016 - 2022 Malta, Valletta - Call sign: 9HA4374 |
|
GT |
4.295 t |
|
DWT |
Summer: 7.479 t |
|
NT |
2.141 t |
|
Light ship |
2.200 t |
|
Length |
116,35 m overall 110,09 m between perpendiculars |
|
Breadth |
15,11 m |
|
Draught |
Max: 6,75 m |
|
Keel to mast end |
30,70 m |
|
Freeboard |
2.559 mm |
|
Keel to mast end |
30,70 m |
|
Depth |
9,30 m moulded |
|
Speed |
14,2 knots laden 14,5 knots ballast |
|
Built |
2004 |
|
Launch date |
15/05/2004 |
|
Date of completion |
02/07/2004 |
|
Builder |
Scheepswerf Ferus Smit B.V. Westerbroek The Netherlands |
|
Yard number |
344 |
|
Hull material |
Special steel |
|
Hull type |
Double hull |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 8L32 - 4 stroke single acting 8 cylinder 320 x 480 mm combustion engine 3.840 kW / 5.217 bhp at 600 rpm Build: 01/2004 Builder: Caterpillar Motoren GmbH & Co. KG, Kiel - Germany |
|
Propellers |
1x Screw propeller controllable pitch |
|
Boilers |
1x CHR Norkem 204,00 m² - 10,0 bar 2x CHO AKB 32,07 m² - 10,0 bar |
|
Generators |
3x Volvo Penta D12 main diesel generatorsets each 487 kVA - 390 kW - 503 hp |
|
Emergency generator |
1x Diesel generatorset 54 kVA - 43 kW - 65 hp |
|
Bow thruster |
1x Berg pitch thruster 260 kW |
|
Number of tanks |
12 + 2 slop tanks |
|
Cargo tank capacity |
100% - 8.208 m³ 98% - 8.046 m³ |
|
Segregations |
5x Double valve |
|
Number of slop tanks |
2 |
|
Slop tank capacity |
Port: 152,1 m³ Starboard: 183,5 m³ |
|
Number of pumps |
5x Cargo pumps Framo SD150 each 300 m³/h |
|
Loading Capacity |
1.600 m³/h |
|
Discharge capacity |
1.200 m³/h |
|
Tank capacities |
Ballast: 3.104 m³ HFO: 293 m³ Diesel oil: 62 m³ Fresh water: 77 m³ |
|
Lifting equipment |
1x Deck crane - SWL 1,5 t outreach 2,00 m |
|
Commercial manager |
Wisby Tankers AB Fabriksgatan 4 531 30 Lidköping Sweden |
|
ISM manager |
Wisby Shipmanagement AB Fabriksgatan 4 531 30 Lidköping Sweden |
|
Owner |
WT Tankers B.V. Zuidlaren Groningen The Netherlands |
|
Previous owners |
07/2004 - 08/2009 Ljugarn AB - Sweden 08/2009 - 04/2013 Wisby Tankers AB, Visby - Sweden |
|
Latest data adjustment |
24 September 2023 |
