Rojas 01

Antwerpen 31 December 2019



Name

ROJAS

Type

Inland tanker

ENI-number

02333567

Call sign

PB8229

Flag

The Netherlands

Port of registry

Wemeldinge

Tonnage

3.123 t

Length

109,96 m

Breadth

11,45 m

Draught

3,76 m

Depth

5,30 m

Built

2009

Builder casco

Zhenjiang HongXing

Taizhou

China

Builder completion

Smits Machinefabriek en Scheepsreparatie B.V

Capelle a/d IJssel

The Netherlands

Hull material

Steel

Main engine

1x Caterpillar 3512 (C) DI-TA electronic combustion engine 1.119 kW /1.521 hp at 1.600 rpm

Gearbox

1x Reintjes type WAF 665 L - reduction 5,044:1

Propellers

1x 5 Blades propeller - diameter 1.750 mm in nozzle Giessen Optima diameter 1.762 mm

Generators

1x Caterpillar C18 Acert diesel engine 485 hp at 1.800 rpm connected with Stamford generator 356 kW

1x Caterpillar C12 diesel engine 390 hp at at 1.800 rpm connected with Stamford generator 287 kW

2x Caterpillar Type C4.4 diesel generatorset each 87 kVA at 1.500 rpm

Bow thruster

Caterpillar - Verhaar Omega-Jet 31120-4k - 330 kW at 1.780 rpm

Pumps

2x Bornemann type EPS500 cargo pumps each 500 m³/h connected with ABB electro-motor each 230 kW

2x Screw spindle pump type EPS10 pumps each 10 m³/h connected with ABB electro-motor each 7,5 kW

Cargo hold capacity

3.731 m³

Owner

Dari BV

Dordrecht

The Netherlands

Previous names & owners

2010 - 2020 Baccarat BV, Wemeldinge - The Netherlands

Latest data adjustment

07 June 2020
