Westerschelde 17 April 2020 |
 |
 |
|
| Westerschelde 04/12/20 | Westerschelde 23/07/15 | |
|
Name |
JO ROWAN |
|
Type |
Tanker for chemicals & oil products |
|
IMO-number |
9602710 |
|
Call sign |
LAPO7 |
|
Flag |
Norway |
|
Port of registry |
Bergen |
|
GT |
43.053 t |
|
DWT |
Summer: 73.811 t |
|
NT |
21.674 t |
|
Displacement |
90.329 t |
|
Length |
228,59 m overall 219,70 m between perpendiculars |
|
Breadth |
32,29 m extreme 32,26 m moulded |
|
Draught |
Summer: 14,65 m |
|
Keel to mast end |
49,00 m |
|
Freeboard |
6.568 mm |
|
Depth |
21,20 m moulded |
|
Speed |
Max: 14,6 knots |
|
Built |
2013 |
|
Keel laid |
28/12/2011 |
|
Date of completion |
16/08/2013 |
|
Builder |
New Times Shipbuilding Co. Ltd. Dan Hua Gang Port Jingiang City China |
|
Yard number |
0307369 |
|
Hull material |
Steel - Part higher tensile steel |
|
Hull type |
Double hull |
|
Number of decks |
1 |
|
Main engine |
1x MAN-B&W 5S60MC-C8 - 2 stroke 5 cylinder 600 x 2.400 mm combustion engine Mcr 11.300 kW / 16.179 hp at 105,0 rpm |
|
Propellers |
1x Fixed pitch propeller - 4 blades Manufacturer: Wärtsilä CME Zhenjiang propeller Co., Ltd. |
|
Boilers |
2x Auxiliary oil fired boiler MISSION OL 20T/H - 18,0 MPa each 1x Unfired exhaust gas boiler |
|
Generators |
3x MAN 6L23/30H 4 stroke 6 cylinder 225 x 300 mm diesel engines each 960 kW connected with Taiyo FE553B-10 generators each 900 kW |
|
Number of cargo tanks |
12 + 2 slop tanks |
|
Cargo tank capacity |
98% - 81.486 m³ 100% - 86.134,46 m³ |
|
Number of slop tanks |
2 |
|
Pumps |
12x Cargo pumps each 900 m³/h |
|
Manifolds |
Distance bow to centre manifold: 114,50 m Distance stern to centre manifold: 113,50 m |
|
Tank capacities |
Ballast: 29.515,52 m³ Fresh water: 720,41 m³ Fuel oil: 2.015,22 m³ Lub oil: 119,40 m³ Diesel oil: 248,20 m³ |
|
Lifting equipment |
1x Engine room overhead crane - SWL 4,5 t 1x Provision crane - SWL 5,0 t Manufacturer: Bolin Engineering & Machinery co., Ltd. 1x Hose handling crane - 15,0 t Manufacturer: TTS Marine (Shanghai) Co.,Ltd. |
|
Crew |
22 |
|
Commercial manager |
Nyhill Shipping & Trading AS C Sundts gate 1 5004 Bergen Norway |
|
ISM manager |
Wallem GmbH & Co. KG Sprinkenhof, 3rd Floor Burchardstrasse 8 20095 Hamburg Germany |
|
Registered owner |
Hassel Shipping 2 AS, 5008 Bergen - Norway Care of Nyhill Shipping & Trading AS C Sundts gate 1 5004 Bergen Norway |
|
Renamed |
03/2023 Torm Integrity 2023 Marshall Islands, Majuro 2023 Denmark, Vejle - Call sign: OUZG2 Charterer: Torm A/S, 2900 Hellerup - Denmark Owner: Sea 347 Leasing Co Ltd., Hellerup - Denmark |
|
Latest data adjustment |
28 September 2024 |
