Westerschelde 07 May 2019 |
 |
 |
|
| Westerschelde 06/05/19 | Westerschelde 06/05/19 | |
|
Name |
MINERVA CORALIA |
|
Type |
Crude oil tanker- Aframax |
|
IMO-number |
9728239 |
|
Call sign |
9HA4413 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
GT |
62.513 t Suez: 63.979,43 t |
|
DWT |
113.850,21 t |
|
NT |
35.199 t Suez: 58.117,61 t Panama: 51.360 t |
|
Displacement |
Lightship: 19.232,29 t |
|
Length |
249,90 m overall 242,00 m between perpendiculars |
|
Breadth |
44,03 m moulded |
|
Draught |
Summer: 15,02 m |
|
Freeboard |
6.218 mm |
|
Depth |
21,20 m moulded |
|
Speed |
14,5 knots |
|
Built |
2017 |
|
Keel laid |
14/12/2015 |
|
Launch date |
29/10/2016 |
|
Delivery date |
16/01/2017 |
|
Builder |
Daewoo Mangalia Heavy Industries 1, Portului Street Mangalia, Constanta Romania |
|
Yard number |
5023 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x Hyundai/MAN-B&W 6G60ME-C9.5 - 6 cylinder 600 x 2.790 mm combustion engine 11.140 kW / 14.940 bhp at 81,9 rpm Manufacturer: HHI Engine & Machinery Div. |
|
Propellers |
1x Manufacturer: Sil La Metal Co. |
|
Boilers |
1x Fired boiler Aalborg (Mission) OL - 18,0 MPa 1x Fired boiler Aalborg (Mission) OL - 18,0 MPa Manufacturer: Alfa Laval Qingdao Ltd. 1x Fired exhaust gas boiler - 8,0 MPa Manufacturer: Saacke Qingdao Marine Boiler Co., Ltd. |
|
Generators |
3x Main diesel generatorsets each 900 kW Manufacturer: HHI Electro Electric System |
|
Cargo tank capacity 98% |
124/517,4 m³ excluding slop tanks |
|
Slop tank capacity 98% |
2821,7 m³ |
|
Pumps |
3x Cargo pumps 3.000 m³/h each |
|
Tank capacities |
Fresh water: 465,70 m³ Fuel oil: 2.177,00 m³ Lube oil: 171,60 m³ Ballast: 41.210,00 m³ Diesel oil: 153,30 m³ |
|
Lifting equipment |
1x Engine room crane - SWL 4,0 t 1x Hose handling care port - SWL 15,0 t 1x Hose handling care starboard - SWL 15,0 t 1x Monorail crane - SWL 4,0 t Manufacturer: Oriental Precision Machinery Co., Ltd. |
|
Crew size |
30 |
|
Manager |
Minerva Marine Inc. 141-143, Vouliagmenis Avenue Voula, 166 73 Athens Greece |
|
Registered owner |
Arion Shipmanagement Corporation c/o Minerva Marine Inc 141-143, Vouliagmenis Avenue Voula, 166 73 Athens Greece |
|
Latest data adjustment |
13 April 2021 |
