Westerschelde 19 June 2020 |
|
Name |
ZEYNEP KA |
|
Previous names |
2008 - 2015 Lady Ferhan |
|
Type |
Oil tanker / Chemical tanker |
|
IMO-number |
9445411 |
|
Call sign |
TCTF8 |
|
Flag |
Turkey |
|
Port of registry |
Istanbul |
|
GT |
4.347 t |
|
DWT |
Summer: 6.276 t |
|
NT |
2.034 t |
|
Length |
121,62 m overall 112,17 m between perpendiculars |
|
Breadth |
16,00 m moulded |
|
Draught |
Summer: 6,33 m 4,23 m ballast |
|
Height from keel to mast |
33,30 m |
|
Air draft |
Ballast: 27,64 m Loaded condition: 26,96 m |
|
Freeboard |
1.680 mm |
|
Depth |
8,00 m |
|
Speed |
Service: 11,0 knots Max: 14,0 knots |
|
Built |
2008 |
|
Date of completion |
20/06/2008 |
|
Builder |
Sahin Celik Tersanesi San. Ve Tic. A.S. Turkey |
|
Yard number |
44 |
|
Hull material |
Steel |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 8M25 - 4 stroke 8 cylinder 255 x 400 mm combustion engine 2.640 kW / 3.540 bhp at 750 rpm Builder: MaK Deutschland Zweign. Caterpillar Motoren GmbH |
|
Propelling system |
1x Screw propeller controllable pitch |
|
Boilers |
1x CHR 58,00 m² - 10,0 bar 2x CHO 40,70 m² - 10,0 bar 1x CHS Alfa Naval Spa,10592 16,00 m² - 12,0 bar |
|
Generators |
3x Caterpillar C18 Dita main diesel generatorsets each 533 kVA - 426 kW - 632 hp |
|
Emergency generator |
1x Diesel generatorset 118 kVA - 94 kW - 139 hp |
|
Bow thruster |
1x 350 kW / 475 bhp |
|
Number of cargo tanks |
12 |
|
Cargo tank capacity 98% |
Tank 1: 447,179 m³ & 545,073 m³ Tank 2: 294,396 m³ & 590,114 m³ Tank 3: 667,715 m³ & 666,501 m³ Tank 4: 668,372 m³ & 669,455 m³ Tank 5: 667,757 m³ & 668,266 m³ Tank 6: 545,883 m³ & 553,339 m³ Total: 7.189,13 m³ |
|
Number of slop tanks |
2 |
|
Slop tank capacity 98% |
Port & Starboard 71,993 m³ & 71,807 m³ Total: 143,79 m³ |
|
Number of pumps |
12x Centrifugal cargo pumps each 200 m³/h 2x Centrifugal cargo pumps each 80 m³/h |
|
Manifolds |
Distance from bow to centre manifold: 66,62 m Distance from stern to centre manifold: 55,00 m Distance between manifolds: 0,47 m Distance from ship side to manifold: 3,40 m Distance from deck / centre of manifold: 19,40 m |
|
Tank capacities |
Fuel: 229,83 m³ Ballast: 2.795,1 m³ |
|
Lifting equipment |
1x Hose handling crane - SWL 5,0 t |
|
Crew |
13 |
|
Manager |
Trans Ka Tanker Management Co. Daire 57A Denizciler Is Merkezi Sahilyolu Bulvari 25 Aydintepe Mah, Tuzla 34947 Istanbul Tirkey |
|
Registered owner |
Ka Denizcilik Nakliyat Ve Ticaret Limited Şirketi Tuzla - Istanbul Turkey |
|
Previous names & owners |
2008 - 2015 Lady Ferhan - Gemmar Gemi Isletmeleri AS |
|
Latest data adjustment |
05 May 2021 |
