Westerschelde 24 December 2018 |
 |
 |
|
| Westerschelde 24/12/18 | Westerschelde 21/12/18 | |
|
Name |
ATLANTIC LEO |
|
Previous names |
2008 - 06/2008 Overseas Leo |
|
Type |
Oil products tanker |
|
IMO-number |
9381768 |
|
Call sign |
VRDX7 |
|
Flag |
Hong Kong - China |
|
Port of registry |
Hong Kong |
|
GT |
29.266 t |
|
DWT |
49.999 t |
|
NT |
13.129 t |
|
Length |
183,21 m overall |
|
Breadth |
32,00 m moulded |
|
Draught |
Summer: 12,76 m |
|
Moulded L x B x D |
174,00 x 32,20 x 18,80 m |
|
Registered L x B x D |
175,56 x 32,20 x 18,80 m |
|
Freeboard |
Summer: 6.066 mm |
|
Depth |
18,80 m |
|
Speed |
14,5 knots |
|
Built |
2008 |
|
Keel laid |
31/01/2008 |
|
Launch date |
02/04/2008 |
|
Delivery date |
04/06/2008 |
|
Builder |
Hyundai Mipo Dockyard Co. Ltd. Ulsan South Korea |
|
Yard number |
2009 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Bulkheads |
Non tight: 1 Water tight: 8 Oil tight: 8 |
|
Continuous decks |
1 |
|
Main engine |
1x Hyundai/MAN B&W 6S50MC-C 6S50MC- 2 stroke single acting 6 cylinder 500 x 2.000 mm combustion engine 9.480 kW at 127,0 rpm Manufacturer: Hyundai Heavy Industries Co., Ltd. |
|
Propeller shaft |
1x Oil lubrication shaft without monitoring device Diameter: 500 mm |
|
Propellers |
1 |
|
Boilers |
1x Water tube composite boiler - 0,9 MPa Evaporation: 19,10 t/h Manufacturer: Kangrim Heavy Industry Co., Ltd. |
|
Generators |
3x Main diesel generatorsets each 730 kW |
|
Number of cargo tanks |
12 |
|
Cargo tank capacity |
Liquid: 54.164,9 m³ |
|
Number of slop tanks |
2 |
|
Slop tank capacity |
1.175 m³ |
|
Number of pumps |
12x Framo cargo pumps each 600 m³/h 2x Framo cargo pumps each 300 m³/h 1x Framo cargo pumps 150 m³/h 2x Framo ballast pumps each 900 m³/h |
|
Maximum loading rate |
3.600 m³/h |
|
Maximum discharging rate |
3.600 m³/h |
|
Tank capacities |
Fuel oil: 1.698 m³ Fresh water: 292,8 m³ Ballast: 23.893 m³ |
|
Lifting equipment |
1 x Hose handling crane - SWL 10,0 t x 24,00 m 1 x Engine room crane - SWL 2,0 t x 5,10 m 1 x Provision crane - SWL 2,0 t x 9,50 m |
|
Crew size |
25 |
|
Manager |
Executive Ship Management Pte Ltd. 78 Shenton Way #21-00, Singapore 079120 Republic of Singapore |
|
Registered owner |
Leo Maritime Ltd. |
|
Renamed |
09/2019 Velos Leo Marshall islands, Majuro - Call sign: V7A2642 Reg. Owner: Leo Maritime Ltd. Manager: Velos Tankers Ltd., Athens - Greece |
|
Latest data adjustment |
13 July 2021 |
