Westerschelde 28 August 2020 |
 |
 |
|
| Westerschelde 28/08/20 | Westerschelde 28/08/20 | |
|
Name |
TORC |
|
Previous names |
2010 - 2017 Atlantik Glory 2017 - 2020 FMT Knidos |
|
Type |
Oil tanker / Chemical tanker |
|
IMO-number |
9544683 |
|
Call sign |
9HA2351 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
GT |
8.391 t |
|
dwt |
summer: 13.213,7 t winter: 12.786,20 t |
|
NT |
4.174 t |
|
Length |
135,59 m overall 127,65 m between perpendiculars |
|
Breadth |
20,60 m |
|
Draught |
Summer: 8,51 m Winter: 8,34 m |
|
Keel to mast end |
35,48 m |
|
Freeboard |
3.511 mm |
|
Speed |
Max: 14,0 knots |
|
Built |
2010 |
|
Date of completion |
06/04/2010 |
|
Builder |
Selah Makina Ve Gemicilik End. Tic. A.S. Tuzla, Istanbul Turkey |
|
Yard number |
55 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Continuous decks |
1 |
|
Main engine |
1x STX/Man-B&W 9L32/40 - 4 stroke 9 cylinder 320 x 400 mm combustion engine 4.439 kW / 6.114 bhp at 750 tpm Builder: STX Engine Co., Ltd., Changwon - South Korea |
|
Propellers |
1x Screw propeller controllable pitch - aft at 126 rpm |
|
Boilers |
2x CHO PWT Prozess 91,20 m² - 10,0 bar 1x CHR PWT Prozess 67,00 m² - 10,0 bar |
|
Shaft generator |
1x 1.160 kW |
|
Generators |
3x Main diesel generatorsets each 775 kVA - 620 kW - 842 hp |
|
Emergency generator |
1x Diesel generatorset 120 kW |
|
Bow thruster |
1x 522 kW |
|
Number of cargo tanks |
12 |
|
Cargo tank capacity 98% |
Liquid: 14.140,61 m³ |
|
Number of slop tanks |
2 |
|
Slop tank capacity 98% |
297,52 m³ |
|
Segregations |
14x (double valve) |
|
Number of pumps |
12x Cargo pumps each 300 m³/h |
|
Manifolds |
Bow to centre manifolds: 64,41 m |
|
Tank capacities |
Fuel: 625,8 m³ |
|
Lifting equipment |
1x Crane - SWL 5,0 t 1x Crane - SWL 2,0 t |
|
Crew size |
18 |
|
Commerical manager |
Besiktas Likid Tasimacilik Kat 15, Blok A, Piyale Pasa Bulvari Memorial Centre, Okmeydani, Sisli 34385 Istanbul Turkey |
|
ISM manager |
Besiktas Likid Tasimacilik Kat 15, Blok A, Piyale Pasa Bulvari Memorial Centre, Okmeydani, Sisli 34385 Istanbul Turkey |
|
Registered owner |
Torc Shipping Ltd. Care of Besiktas Likid Tasimacilik Denizcilik Ticaret AS, Kat 15, Blok A, Piyale Pasa Bulvari Memorial Centre, Okmeydani, Sisli 34385 Istanbul Turkey |
|
Latest data adjustment |
08 August 2021 |
