Vlissingen, The Netherlands 25 May 2019 |
 |
 |
 |
||
| Westerschelde 25/05/19 | Vlissingen 23/05/19 | Westerschelde 29/01/20 | ||
|
Name |
BOW LIND |
|
Previous names |
2010 Stolt Gulf Mishref 2010 Gulf Mizhar 2011 Stolt Golf Mizhar |
|
Type |
Tanker for chemicals and oil products |
|
IMO-number |
9388314 |
|
Call sign |
LAPV8 |
|
Flag |
Norway |
|
Port of registry |
Bergen |
|
Previous flag |
2011 - 2022 Republic of Singapore, Singapore City - Call sign: 9V9234 |
|
GT |
26.327 t Suez: 26.959 t |
|
DWT |
Summer: 46.047 t |
|
NT |
14.405 t |
|
Light ship |
11.188 t Suez: 22.733 t Panama: 21.984 t |
|
Length |
182,88 m overall 175,60 m between perpendiculars |
|
Breadth |
32,23 m extreme |
|
Draught |
Summer: 12,07 m |
|
Keel to top mast |
47,51 m |
|
Depth |
16,05 m |
|
Speed |
15,0 knots |
|
Built |
2011 |
|
Keel laid |
14/12/2009 |
|
Launch date |
12/07/2010 |
|
Date of completion |
13/05/2011 |
|
Builder |
SLS Shipbuilding Yard Co. Ltd. Tongyeong South Korea |
|
Yard number |
S489 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Continuous decks |
1 |
|
Main engine |
1x MAN-B&W/Doosan 5S60MC - 2 stroke 5 cylinder 600 x 2.400 mm combustion engine 11.300 kW / 15.363 hp at 105,0 rpm |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
2x Auxiliary boiler, oil/gas fired - Mission OL 1x Auxiliary boiler, exhaust gas heated - Mission XW Manufacturer: Aalborg |
|
Generators |
3x Yanmar 8N21AL-EV 4 stroke 8 cylinder 210 x 290 mm diesel engines each Mcr 1.300 kW |
|
Emergency generator |
1x Cummins NT 855 D(M) diesel generatorset |
|
Bow thruster |
1x 986 kW |
|
Number of tanks |
29 |
|
Cargo hold capacity |
Liquid: 47.729 m³ |
|
Number of pumps |
14x cargo pumps each 360 m³/h 15x cargo pumps each 220 m³/h |
|
Manifolds |
Summer waterline to manifold: 6,29 m Normal ballast waterline to manifold: 11,71 m Rail to manifold: 2,50 m Bow to centre of manifold: 90,70 m |
|
Tank capacities |
Ballast: 17.858,4 m³ |
|
Anchor equipment |
Length: 632,60 m Diameter: 73 mm |
|
ISM & commercial manager |
Odfjell Management AS Conrad Mohrs veg 29 5892 Bergen Norway |
|
Registered owner |
Odfjell Chemical Tankers Ii As Conrad Mohrs Veg 29 5072 Bergen Norway |
|
Previous owners |
Odfjell Asia II Pte Ltd. Oue Downtown 2 6, Shenton Way Singapore 068809 republic of Singapore |
|
Latest data adjustment |
18 August 2021 |
