Westerschelde 01 July 2020 |
 |
| Westerschelde 07/09/18 |
|
Name |
HAFNIA GREEN |
|
Previous names |
2007 - 05/2014 Mount Green |
|
Type |
Chemical/Oil products tanker |
|
IMO-number |
9360441 |
|
Call sign |
9V3233 |
|
Flag |
Republic of Singapore |
|
Port of registry |
Singapore City |
|
Previous flags |
2007 - 2015 Cyprus, Limassol - Call sign: C4VJ2 |
|
GT |
22.521 t Suez: 23.599,84 t |
|
DWT |
Summer: 39.807 t Winter: 38.895 t |
|
NT |
11.314 t Suez: 22.788,22 t Panama: 18.768,44 t |
|
Lightweight |
8.320 t |
|
Displacement |
Summer: 48.128 t |
|
Length |
181,78 m overall 173,81 m between perpendiculars |
|
Breadth |
27,42 m extreme |
|
Draught |
Summer: 11,93 m Winter: 11,72 m |
|
Keel to mast end |
46,25 m |
|
Air draft |
Summer deadweight: 35,45 m Normal ballast: 38,03 m Lightship: 43,91 m |
|
Freeboard |
Summer: 6.137 t |
|
Depth |
16,91 m moulded |
|
Speed |
Max: 15,5 knots 14,5 knots fully laden |
|
Built |
2007 |
|
Keel laid |
11/12/2006 |
|
Launch date |
09/04/2007 |
|
Date of completion |
03/08/2007 |
|
Builder |
Saiki Heavy Industries Co., Ltd. 5-37 Tsuruya-Machi 2-Chome Saiki City Oita 876 Saiki City, 876 Japan |
|
Yard number |
1161 |
|
Hull material |
Ordinary strength steel |
|
Hull type |
Double hull |
|
Bulkheads |
Water tight: 4 Oil tight: 12 |
|
Continuous decks |
1 |
|
Main engine |
1x Mitsubishi 6UEC52LS - 2 stroke 6 cylinder 520 x 1.850 mm combustion engine 7.980 kW / 10.799 hp at 120 rpm Manufacturer: Akasaka Diesel Limited. (Mitsubishi Heavy Ind., Ltd.) |
|
Propellers |
1x Fixed pitch propeller - 4 blades Manufacturer: Nakashima Propeller Co., Ltd. Tamashima Works |
|
Boilers |
1x Auxiliary boiler (vertical oil fired) - 8,0 bar 1x Exhaust gas boiler - 7,0 bar Manufacturer: Osaka Boiler Mfg.Co.,Ltd. |
|
Generators |
3x Yanmar 6W18(AL)-V main diesel generatorsets each 600 ekW Manufacturer: Nishishiba Electric Co., Ltd. |
|
Bow thruster |
1x 650 kW / 884 bhp |
|
Number of cargo tanks |
12 |
|
Cargo tank capacity 98% |
Seg#1: 5.727,61 m³ (1p,1s) Seg#2: 7.079,77 m³ (2p,2s) Seg#3: 7.171,81 m³ (3p.3s) Seg#4: 7.165,43 m³ (4p.4s) Seg#5: 7.183,72 m³ (5p,5s) Seg#6: 6.625,61 m³ (6p,6s) Total cubic capacity (98%, excluding slop tanks): 40.993,63 m³ |
|
Number of slop tanks |
2 |
|
Slop tanks capacity 98% |
1.259,31 m³ |
|
Number of pumps |
12x Centrifugal cargo pumps each 500 m³/h 2x Centrifugal cargo pumps each 200 m³/h 1x Centrifugal cargo pump 100 m³/h 2x Centrifugal ballast pumps each 600 m³/h 1x Ballast ejector 100 m³/m |
|
Manifolds |
Distance bridge front to centre of manifold: 59,00 m Bow to centre manifold: 90,38 m Stern to centre manifold: 61,40 m Distance between cargo manifold centres: 2.000 mm Distance ships rail to manifold: 4.440 mm Distance manifold to ships side: 4/640 mm Top of rail to centre of manifold: 700 mm Distance main deck to centre of manifold: 1.900 mm Spill tank grating to centre of manifold: 850 mm |
|
Tank capacities |
Diesel Oil: 187,64 m³ Freshwater: 335,55 m³ Fuel Oil: 1.254,82 m³ Lube Oil: 134,73 m³ Tank Ballast: 16.270,97 m³ |
|
Lifting equipment |
1x Hose handling crane - SWL 10,0 t Manufacturer: Mitsubishi Heavy Ind. Ltd. 1x Hose handling crane - SWL 3,0 t Manufacturer: Fujiki Co.,Ltd. 1x Provision crane - SWL 2,5 t Manufacturer: Mansei Industry Co.,Ltd. |
|
Crew size |
29 |
|
Commerical manager |
Hafnia Pools Pte. Ltd. Mapletree Business City 10 Pasir Panjang Road #18-01 Singapore 117438 Republic of Singapore |
|
Technical manager |
Donnelly Tanker Management Ltd 44-46 Vouliagmenis Avenue, 16673 Athens Greece |
|
Registered owner |
Hafnia Tankers Shipholding Singapore Pte Ltd. 159 Telok Ayer Street Singapore 068614 Republic of Singapore |
|
Renamed |
2022 Velos Topaz Marshall Islands, Majuro - Call sign: V7A5632 |
|
Latest data adjustment |
09 September 2022 |
