Westerschelde 14 February 2020 |
 |
 |
 |
||
| Westerschelde 14/02/20 | Westerschelde 14/02/20 | Westerschelde 14/02/20 | ||
|
Name |
ASTREA |
|
Previous names |
2006 - 2018 Ray G |
|
Type |
Chemical/Oil products tanker |
|
IMO-number |
9293997 |
|
Call sign |
9HA4931 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
Previous flags |
2006 - 2018 Italy, Napoli - Call sign: IBXM |
|
GT |
25.431 t Suez: 26.845,84 t |
|
DWT |
Summer: 40.158 t |
|
NT |
10.019 t Suez: 22.554,06 t |
|
Displacement |
49.258,43 t |
|
Light weight |
9.200 t |
|
Length |
175,98 m overall 168,00 m between perpendiculars |
|
Breadth |
31,00 m moulded |
|
Draught |
Summer: 11,12 m |
|
Keel to mast end |
43,53 m |
|
Freeboard |
6.114 mm |
|
Depth |
17,20 m moulded |
|
Speed |
15,0 knots |
|
Built |
2006 |
|
Delivery date |
27/01/2006 |
|
Builder |
Shina Shipbuilding Co. Ltd. Head Office 227, Donam-Dong Tongyeong Gyeongnam, 650-150 South Korea |
|
Yard number |
443 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Main engine |
1x MAN-B&W/STX 7S50MC-C - 2 stroke 7 cylinder 500 x 2.000 mm combustion engine 11.060 kW at 127,0 rpm Manufacturer: STX Engine Ltd. Build: 18/08/2005 |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Auxiliary oil fired water tube boiler Mission OL - 9,0 MPa 1x Composite oil fired water tube boiler Mission OC - 9,0 MPa |
|
Generators |
4x Main diesel generatorsets each 757 kW / 400 Volt 60 Hz |
|
Number of tanks |
12 + 2slop ytanks |
|
Cargo tank capacity 100% |
55.440,14 m³ |
|
Number of slop tanks |
2 |
|
Number of pumps |
12x Cargo pumps each 500 m³/h |
|
Tank capacities |
Ballast: 23.027,09 m³ Lub oil: 106,47 m³ Fresh water: 363,83 m³ Fuel oil: 1.549,48 m³ Diesel oil: 242,18 m³ |
|
Lifting equipment |
1x Engine room crane - SWL 2,8 t 1x Hose handling - SWL 10,0 t 1x Hose handling/Provision crane - SWL 3,0 t |
|
ISM & commercial manager |
Chandris Hellas Inc. 95, Akti Miaouli 185 38 Piraeus Greece |
|
Registered owner |
Sictus 10 Ltd. Care of Chandris (Hellas) Inc. 95, Akti Miaouli 185 38 Piraeus Greece |
|
Renamed |
09/2022 Strea Liberia, Monrovia - Call sign: 5LHX5 Owner: HS Strea Ltd., Monrovia - Liberia Operator: Maritas Fleet Private Limited, Navi Mumbai - India |
|
Latest data adjustment |
04 May 2023 |
